ELECTRICAL PARTS LIST
Pos.
12 NC Description
14PV120/07
14PV125/01
14PV125/07
14PV125/39
14PV125/58
14PV225/01
14PV225/07
14PV225/39
14PV422/58
14PV225/58
14PV422/01
14PV422/07
14PV422/39
CN302 9965 000 13916 CONNECTOR, 8P TUC-P08X-B1 1111111111111
CN303 9965 000 13841 CONNECTOR BASE, 5P TUC-P05P-B1 1111111111111
CN603 9965 000 18089 CONNECTOR 13P TUC-P13X-B1 1111111111111
CN751 9965 000 13842 CONNECTOR BASE, 8P TUC-P08P-B1 1111111111111
CN752 9965 000 13843 CONNECTOR BASE, 6P TUC-P06P-B1 1111111111111
CN804 9965 000 13844 STRAIGHT CONNECTOR BASE 1111111111111
D151 9965 000 13848 ZENER DIODE MTZJT-777.5B 1111111111111
D152 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D201 9965 000 05250 LED SIR-563ST3F P 1111111111111
D202 9965 000 13846 LED(RED) L-1513EC 1111111111111
D204 9965 000 13846 LED(RED) L-1513EC 1111111111111
D205 9965 000 05249 ZENER DIODE MTZJT-775.6B 1111111111111
D206 PCB JUMPER D0.6-P5.0 1111111111111
D210 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D211 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D212 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D213 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D214 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D302 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D303 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D304 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D305 9965 000 11153 ZENER DIODE MTZJT-778.2B 1111111111111
D306 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D401 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D402 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D471 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1 1 1
D682 PCB JUMPER D0.6-P10.0 1111111111111
D686 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D687 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D688 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D690 9965 000 13848 ZENER DIODE MTZJT-777.5B 1111111111111
D691 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D693 9965 000 18090 ZENER DIODE MTZJT-776.2A 1111111111111
D694 9965 000 18091 ZENER DIODE MTZJT-7715B 1111111111111
D706 9965 000 12904 ZENER DIODE DZ-5.1BSBT265 1111111111111
D711 9965 000 05249 ZENER DIODE MTZJT-775.6B 1111111111111
D712 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D713 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D715 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D716 9965 000 05249 ZENER DIODE MTZJT-775.6B 1111111111111
IC151 9965 000 13853 AUDIO AMP LA4224 1111111111111
IC201 9965 000 18092 MICRO COMPUTER M37762MCA-BA2GP 1111111111111
IC202 9965 000 13030 IC:MEMORY BR24C04F-W 1111111111111
IC301 9965 000 18093 IC:CHROMA/IF 1 CHIP M61209BFP 1111111111111
IC401 9965 000 12180 IC:Y/C/A LA71750AM-MTB 1111111111111
IC471 9965 000 13927 IC:SECAM LA70100M-MPB 1 1 1
IC681 9965 000 13851 VOLTAGE REGULATOR KIA7805API 1111111111111
IC701 9965 000 13852 IC:SWITCH TC4053BF(N) 1111111111111
IC703 9965 000 13852 IC:SWITCH TC4053BF(N) 1111111111111
JK151 9965 000 13855 HEADPHONE JACK MSJ-035-10A B 1111111111111
JK701 4822 265 11659 RCA JACK(YELLOW) MSP-281V4-B 1111111111111
JK702 4822 265 11661 RCA JACK(WHITE) MSP-281V1-B 1111111111111
JK703 9965 000 13854 SKIRT JACK 21P HRC-21V-02P 1111111111111
L001 PCB JUMPER D0.6-P5.0 1111111111111
