Philips 14PV225 - Page 35

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV120/07 14PV125/01 14PV125/07 14PV125/39 14PV125/58 14PV225/01 14PV225/07 14PV225/39 14PV422/58 14PV225/58 14PV422/01 14PV422/07 14PV422/39
TP006 PCB JUMPER D0.6-P10.0 1111111111111
TP007 PCB JUMPER D0.6-P10.0 1111111111111
TP008 PCB JUMPER D0.6-P12.5 1111111111111
TP009 PCB JUMPER D0.6-P12.5 1111111111111
TP010 PCB JUMPER D0.6-P22.5 1111111111111
X201 9965 000 09200 X’TAL 32.768KHZ(20PPM) 1111111111111
X202 9965 000 12194 X’TAL 12.000MHZ 1111111111111
X301 9965 000 13869 X’TAL 4.433619MHZ 1111111111111
X401 9965 000 05629 X’TAL 4.433619MHZ 1111111111111
CN301 9965 000 13836 LEAD WIRE 4P/300 1111111111111
CN302 9965 000 18115 LEAD WIRE 8P/190 1111111111111
CN603 9965 000 18116 LEAD WIRE 13P/190 1111111111111
Q201 9965 000 18096 PHOTO TRANSISTOR MID-32A22 1111111111111
Q202 9965 000 18096 PHOTO TRANSISTOR MID-32A22 1111111111111
1111111111111
1111111111111
1111111111111
1111111111111
1111111111111
BC551 9965 000 13874 BEAD INDUCTORS FBA04HA600VB-00 1111111111111
BC602 9965 000 13875 BEAD INDUCTORS FBR07HA121TB-00 1111111111111
BC604 9965 000 13875 BEAD INDUCTORS FBR07HA121TB-00 1111111111111
BC605 9965 000 13875 BEAD INDUCTORS FBR07HA121TB-00 1111111111111
C551 ELECTROLYTIC CAP. 2.2UF/50V M LL 1111111111111
C552 ELECTROLYTIC CAP. 1000UF/25V M 1111111111111
C553 CERAMIC CAP.(AX) B K 0.01UF/50V 1111111111111
C554 ELECTROLYTIC CAP. 470UF/35V M 1111111111111
C555 ELECTROLYTIC CAP. 47UF/25V M 1111111111111
C556 ELECTROLYTIC CAP. 2.2UF/50V M 1111111111111
C558 FILM CAP.(P) 0.047UF/50V J 1111111111111
C559 CERAMIC CAP. R K 680PF/2KV(HR) 1111111111111
C560 P.P. CAP 0.0082UF/1.6K J 1111111111111
C561 FILM CAP.(P) 0.01UF/50V J 1111111111111
C562 ELECTROLYTIC CAP. 47UF/25V M 1111111111111
C565 ELECTROLYTIC CAP. 47UF/160V M W/F 1111111111111
C567 ELECTROLYTIC CAP. 1UF/160V M 1111111111111
C569 ELECTROLYTIC CAP. 4.7UF/250V M 1111111111111
C570 ELECTROLYTIC CAP. 1UF/50V M 1111111111111
C572 ELECTROLYTIC CAP. 22UF/50V M 1111111111111
C575 P.P. CAP 0.18UF/200V J 1111111111111
C576 P.P. CAP 0.15UF/200V J 1111111111111
C577 ELECTROLYTIC CAP. 100UF/35V M 1111111111111
C602
h
2020 554 90173 SAFETY CAP. 2200PF/250V KX 1111111111111
C604
h
9965 000 14280 METALLIZED FILM CAP. 0.1UF/250V 1111111111111
C605
h
9965 000 14280 METALLIZED FILM CAP. 0.1UF/250V 1111111111111
C607 CERAMIC CAP. 0.01UF/AC250V 1111111111111
C608 CERAMIC CAP. 0.01UF/AC250V 1111111111111
JUNCTION B CBA
JUNCTION C CBA
CAPACITORS
Consists of the following
JUNCTION D CBA
JUNCTION E CBA
H.V./POWER SUPPLY CBA
COILS
SENSOR CBA
POWER CBA
H.V./POWER SUPPLY CBA
CRT CBA
JUNCTION A CBA
1-14-28
