Philips 14PV225 - Page 37

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV120/07 14PV125/01 14PV125/07 14PV125/39 14PV125/58 14PV225/01 14PV225/07 14PV225/39 14PV422/58 14PV225/58 14PV422/01 14PV422/07 14PV422/39
D621 9965 000 13886 DIODE 1ZC33 1111111111111
D622 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D623 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D624 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D625 4822 130 11629 ZENER DIODE MTZJT-776.8B 1111111111111
D626 9965 000 13885 FAST RECOVERY DIODE CA201-4 1111111111111
D627 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D629 4822 130 81729 ZENER DIODE MTZJT-7733C 1111111111111
D630 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D631 9965 000 13888 ZENER DIODE MTZJT-776.8A 1111111111111
D632 9965 000 09896 CARBON RES. 1/4W J 10K OHM 1111111111111
D633 9965 000 13889 ZENER DIODE MTZJT-7724B 1111111111111
D634 CARBON RES. 1/4W J 100 OHM 1111111111111
D635 9965 000 11153 ZENER DIODE MTZJT-778.2B 1111111111111
D636 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D637 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D638 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111111111
D640 4822 130 11629 ZENER DIODE MTZJT-776.8B 1111111111111
F601
h
9965 000 13890 FUSE 4A/250V 215004 1111111111111
FH601 4822 25610461 FUSE HOLDER MSF-015 1111111111111
FH602 4822 25610461 FUSE HOLDER MSF-015 1111111111111
IC551 9965 000 18120 VERTICAL OUTPUT IC LA78040A 1111111111111
IC601
h
9965 000 13892 PHOTO COUPLER LTV817MBF 1111111111111
L552 PCB JUMPER D0.6-P7.5 1111111111111
L553 9965 000 18121 CHOKE COIL 22UH-K 1111111111111
L554 9965 000 05627 CHOKE COIL 47UH-K 1111111111111
L601 9965 000 13894 LINE FILTER ELF15N007A 1111111111111
L602 9965 000 13894 LINE FILTER ELF15N007A 1111111111111
L603 9965 000 05627 CHOKE COIL 47UH-K 1111111111111
MISCELLANEOUS
PB1 9965 000 18122 POWER PCB HOLDER T6400RA 1111111111111
PB4 13V POW HEAT SINK PAL PHKT6400RA 1111111111111
PB5 9965 000 18123 13V P H/S PAL PHM ASSEMBLY T6400RA 1111111111111
PL1 9965 000 08646 SCREW, P-TIGHT 3X12 WASHER HEAD+ 1111111111111
PL2 9965 000 12171 SCREW, B-TIGHT M3X8 BIND HEAD+ 1111111111111
PL2 SCREW, B-TIGHT M3X8 BIND HEAD+ 1111111111111
PS602 9965 000 13896 THERMISTOR ZPB31BL9R0A 1111111111111
Q551 9965 000 13897 TRANSISTOR TT2084LS-YB11 1111111111111
Q553 9965 000 13899 TRANSISTOR 2SC1627Y-TPE2 1111111111111
Q554 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111111111
Q602 9965 000 13901 MOS FET 2SK2647 1111111111111
Q603 4822 130 42292 TRANSISTOR 2SC2120-Y(TPE2) 1111111111111
Q604 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111111111
Q605 4822 130 63665 TRANSISTOR 2SA950(O) 1111111111111
Q606 4822 130 42292 TRANSISTOR 2SC2120-Y(TPE2) 1111111111111
Q607 4822 130 42292 TRANSISTOR 2SC2120-Y(TPE2) 1111111111111
Q608 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111111111
R551 CARBON RES. 1/4W J 8.2K OHM 1111111111111
R552 CARBON RES. 1/4W J 3.3K OHM 1111111111111
R553 CARBON RES. 1/4W J 22K OHM 1111111111111
R554 CARBON RES. 1/4W J 1K OHM 1111111111111
R555 CARBON RES. 1/4W J 5.6 OHM 1111111111111
R556 CARBON RES. 1/4W J 5.6 OHM 1111111111111
R557 CARBON RES. 1/4W J 10K OHM 1111111111111
