Philips 196V3LSB2/00 - Page 60

!
60
Meridian 3
 IC902 056G-139--9 IC EL817M(X) photocoupler DIP-4 ʳ
 IC801 056G-379185
AC/DC CONVERTER
TA9690GN-A1-0-TR SOP-24
ʳ
 IC901 056G-379190
AC/DC CONVERTER LD7750RGR
SOP-7
ʳ
 IC903 056G-563354 Shunt. Reg. TL431-A-TA TO-92 ʳ
 F1 0FFST-0003A
Fast Blow Fuse ** F0603FA2000V032TM,
AEM, Ceramic, 32V, 2A, UL/CSA,
1.6X0.8X0.8, R/TP
ʳ
 F901 084G--56-4W FUSE 4.0A 250V ʳ
 F902 084G--56-4W FUSE 4.0A 250V ʳ
 E08903 089G-17356C554 AUDIO CABLE 1800MM ʳ
 E08902 089G-725HAA-2G D-SUB CABLE 1500MM ʳ
 E08902 089G-725CAA-2G D-SUB CABLE 1500MM 2nd source
 E08901 089G404A15N-IS AC POWER CORD 1500MM Europe Reg. ʳ
 E08901 089G404A15N-CX AC POWER CORD 1500MM Europe Reg. 2nd source
 E09503 F95G176J-10112 FFC CABLE 10PIN 140MM 0.5MM ʳ
 E09503 F95G176X-10112 FFC CABLE 10PIN 140MM 0.5MM 2nd source
 E09502 F95G8014-7D100 WIRE HARNESS 500MM 7P-7P ʳ
 E09502 F95G8014-7X100 WIRE HARNESS 500MM 7P-7P 2nd source
 E09502 F95G8014-7R100 WIRE HARNESS 500MM 7P-7P 2nd source
 E09501 F95G801830D300 LVDS CABLE 130mm 30P-30P ʳ
 E09501 F95G801830X300 LVDS CABLE 130mm 30P-30P 2nd source
 E09501 F95G801830R300 LVDS CABLE 130mm 30P-30P 2nd source
Recommended Parts List for 196V3LSB/00
ITEM LOCATION PCM CODES DESCRIPTION REMARK
1 FQ101 705GFACS059 BEZEL ASSY 
2 FQ004 KEPCAQV6 KEY BOARD 
3 FQ001 750GMT185W2C21M100 LM185WH2-TRC2 LTD 
4 FQ570 Q52G1801MNT058 MYLAR 
5 FQ003 PLPCB8561GQDB POWER BOARD 
6 FQ002 CBPCAN2PHQI MAIN BOARD 
7 FQ124 A15G1654301201 MAIN_FRAME 
8 FQ102 A34G2633AFL-2B0130 REAR_COVER_L185 
9 FQ110 A37G0269011 HINGE 
10 FQ107 A34G2611AFL-1B0100 STAND TOP 
11 FQ108 A34G2612AFL-1B0100 STAND BOTTOM 
