16. Recommended & Spare Parts List
Recommended Parts List for 196V3LAB/00
ITEM LOCATION PCM CODES DESCRIPTION REMARK
1 FQ101 705GFACS088 BEZEL ASSY
2 FQ004 KEPCAQV6 KEY BOARD
3 FQ419 078G020A--6--V SPEAKER
4 FQ001 750GMT185W2C21M100 LM185WH2-TRC2 LTD
5 FQ570 Q52G1801MNT058 MYLAR
6 FQ003 PLPCB8561GQA5 POWER BOARD
7 FQ005 AUPCAQV1 AUDIO BOARD
8 FQ002 CBPCAN2PHQL MAIN BOARD
9 FQ124 A15G1654301101 MAIN_FRAME
10 FQ102 A34G2633AFL-1B0130 REAR_COVER_L185
11 FQ110 A37G0269011 HINGE
12 FQ107 A34G2611AFL-1B0100 STAND TOP
13 FQ108 A34G2612AFL-1B0100 STAND BOTTOM
14 FQ118 A33G1224AFL-1B0100 HINGE COVER
15 FQ111 705GFACS090 BASE ASSY
 U402 056G2233-11 IC Pm25LD020C-SCE SIOC-8(150mil) 2M ʳ
 U601 056G-616110 AUDIO PAM8007NHR 3W SSOP-24 ʳ
 U602 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L ʳ
 U401 056G-562368 SCALER NT68660FG/B TQFP-100 ʳ
 U703 056G-563161
IC AME8815BEGT180Z 1.5A/1.8V
SOT-223
ʳ
 U702 056G-563520 LDO LSP1117D33AG 1A 3.3V TO-252 ʳ
 U102 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L ʳ
 U103 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L ʳ
 U104 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L ʳ
 U106 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L ʳ
 U107 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L ʳ
 U101 056G1133956 IC CAT24C02WI-GT3 SO-8 ʳ
 U105 056G1133956 IC CAT24C02WI-GT3 SO-8 ʳ
 U402 056G2233-11 IC Pm25LD020C-SCE SIOC-8(150mil) 2M ʳ
 U402 070GHDCP500HDC HDCP CODE ʳ
 X401 093G--2251B--J
CRYSTAL 12MHZ
NXS12.000AC30F-KAB10
