6. Power Management
If you have VESA DPM compliance display card
or software installed in your PC, the monitor
can automatically reduce its power consumption
when not in use. If an input from a keyboard,
mouse or other input device is detected,
the monitor will 'wake up' automatically. The
following table shows the power consumption
and signaling of this automatic power saving
feature:
Power Management Definition
VESA
Mode
Video H-sync V-sync Power Used LED Color
Active ON Yes Yes < 21.8 W (typ.) White
Sleep OFF No No < 0.5 W (typ.)
White
(blink)
Switch Off OFF - - < 0.5 W (typ.) OFF
The following setup is used to measure power
consumption on this monitor.
v Native resolution: 1920 x 1080
v Contrast: 50%
v Brightness: 250 nits
v Color temperature: 6500k with full white
pattern
Note
This data is subject to change without notice.
