Philips 227E3L - Monitor Operation and OSD Navigation

6
2. Setting up the monito
r
2.2 Operating the monitor
Front view product description
Model 227E3L:
5
62347
Switch monitor’s power ON and
OFF
.
Access the OSD menu .
Return to previous OSD level.
Change display format.
Adjust the OSD menu.
Change the signal input source.
SmartImage Lite. There are three
modes to be selected: Standard,
Internet and Game.
Model 227E3LH:
5
62347
Switch monitor’s power ON and
OFF
.
Access the OSD menu .
Return to previous OSD level.
Adjust the speaker volume.
Adjust the OSD menu.
Change the signal input source.
SmartImage Lite. There are three
modes to be selected: Standard,
Internet and Game.
Model 227E3LPH:
5
62347
Switch monitor’s power ON and
OFF
.
Access the OSD menu .
Return to previous OSD level.
Set the sensor level for backlight
automatic control.
Adjust the OSD menu.
Change the signal input source.
SmartImage Lite. There are three
modes to be selected: Standard,
Internet and Game.
