Revision List
EN 2 TPM10.1HE LA1.
2013-Dec-13
back to
div. table
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
Manual xxxx xxx xxxx.1
• Chapter 2: Updated table 2.1 Technical Specifications
.
• Chapter 4: Added figures 4-1 Cable dressing (22" 3008
series), 4-2 Cable dressing (24" 3008 series), 4-3 Cable
dressing (26" 3008 series), 4-4 Cable dressing (32" 3008
series) and 4-5 Cable dressing (39" 3008 series).
• Chapter 5: Updated table 5-2 Factory mode overview
.
• Chapter 6: Updated tables 6-2 White tone default settings
and 6-3 Display code overview
.
• Chapter 7: Updated figure 7-2 Power Architecture
.
• Chapter 10: Added circuit diagrams 10.1 A 715G5309
PSU, 10.3 A 715G5804 PSU, 10.4 A 715G6050 PSU, 10.5
A 380GLP30029DE0 PSU, 10.7 J 715G5230 IR/LED
panel, 10.9 E 715G5252 Keyboard control panel and 10.11
E 715G5869 Keyboard control panel.
• Chapter 11: Added styling sheets 11.1 3008 series 22"
,
11.2 3008 series 24"
, 11.3 3008 series 26", 11.4 3008
series 32" and 11.5 3008 series 39".
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in Table 2-1.
Here is product information available, as well as getting started,
user manuals, frequently asked questions and software &
drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
24 9 10 11
Connection Overview
Mechanics
Block Diagram
Schematics
Styling Wire Dressing Rear Cover Removal SSB Removal Power Supply SSB J (IR/LED) E (Keyboard/Leading Edge)
22HFL3008D/12 2-1 4-1 4-8 4-9 9.1 10.3 10.6 10.8 10.11 11.1
24HFL3008D/12 2-1 4-2 4-8 4-9 9.1 10.1 10.6 10.8 10.11 11.2
24HFL3008W/12 2-1 4-2 4-8 4-9 9.1 10.1 10.6 10.8 10.11 11.2
26HFL3008D/12 2-1 4-3 4-10 4-11 9.1 10.5 10.6 10.7 10.9 11.3
26HFL3008W/12 2-1 4-3 4-10 4-11 9.1 10.5 10.6 10.7 10.9 11.3
32HFL3008D/12 2-1 4-4 4-6 4-7 9.1 10.2 10.6 10.8 10.10 11.4
39HFL3008D/12 2-1 4-5 4-6 4-7 9.1 10.4 10.6 10.8 10.10 11.5
