Philips 24PHA4309/56 - Mechanical Instructions; Cable Dressing (24 4 X09 Series)

Mechanical Instructions
EN 11TPS14.1A LA 4.
2014-Oct-24
back to
div.table
4. Mechanical Instructions
Index of this chapter:
4.1 Cable Dressing
4.2 Service Positions
4.3 Assembly/Panel Removal (for 24PHA4x09 series)
4.4 Assembly/Panel Removal (for 32"/40"/50"PxA4509 series)
4.5 Set Re-assembly
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
4.1 Cable Dressing
Figure 4-1 Cable dressing (24" 4x09 series)
19660_100.eps
CN401
CN403
CN701
CN9903
CN8101
CN601
MAIN POWER SUPPLY
(1054)
A
IR/LED BOARD
(1056)
J
SSB
(1053)
B
ECN701
ECN601
ECN601
ECN403
ECN403
ECN401
ECN401
LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)
CN201
