32PFL4508/F7(A31F2UT)(ME1)
20121205
32PFL4508/F7(A31F2UT)(ME1)
Ref.No. Description Parts No.
MECHANICAL PARTS
A3 REAR COVER A31F0UT 1EM030132
A11 STAND NECK A31M2UT 1EM228000
A13 JACK HOLDER A31M0UT 1EM334000
A15! RATING LABEL A31F2UT ----------
A16 LOGO LABEL A31M2UT ----------
A17 ENERGY GUIDE LABEL A31F2UT ----------
A20 LEADING EDGE COVER A31M2UT 1EM228001
AC601! AC CORD W/O A GND WIRE UL/CSA/1700/NO/BLACK WAC172LTE005
B17 WALL MOUNT BRACKET A11N0UH 1EM434637
B18 WALL MOUNT COVER A2170UT 1EM332137
CL3101 FFC WIRE ASSEMBLY 9PIN 9PIN/WHITE/115MM WX1A31M0S104
CL3701 FFC WIRE ASSEMBLY 23PIN 23PIN/WHITE/98MM WX1A31M0S103
CL3801 WIRE ASSEMBLY 4PIN 4PIN/220MM&45MM WX1A31M0C302
L7 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L23 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L27 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L45 DOUBLE SEMS SCREW M4X10 + BLK FPH34100
SBA1 STAND BASE ASSEMBLY A31M2UT 1ESA34000
SP3801 SPEAKER MAGNETIC 8OHM/8W S0310F14 DS08110XQ002
SP3802 SPEAKER MAGNETIC 8OHM/8W S0310F14 DS08110XQ002
SSK1 STAND SCREW KIT A31M2UT 1ESA34003
S1 CARTON A31F2UT 1EM334817
S3 STYROFOAM TOP A31F2UT 1EM030505
S4 STYROFOAM BOTTOM A31F2UT 1EM030506
S6 SET BAG A1AF8UT 1EM334734
S7 SERIAL NO. LABEL A01PBUH ----------
X1 POLYETHYLENE BAG HDPE 180X340XT0.03 1EM435579
X2! OWNERS MANUAL A31M2UT 1EMN30002
X3 REMOTE CONTROL UNIT YKF335-001 URMT39JHG001
X4 BATTERY R03-B500/01S XB0M451CZB01
X6 QUICK START GUIDE A31M2UT 1EMN30003
X7 REGISTRATION CARD (PHILIPS) A2176UT 1EMN29339
X12 CABLE MANAGEMENT TIE(BLACK) A01F2UH 1EM431197
LCD1 LCD PANEL ASSEMBLY U3FF1PA
Consists of the following
A1 FRONT CABINET A31F2UT 1EM030385
A4 X-PCB COVER A31F0UT 1EM030131
A5 DECORATION PLATE A31M2UT 1EM228002
B12 SHIELD PLATE A31M2UT 1EM334002
CL3006 FFC WIRE ASSEMBLY 30PIN(W//SHIELD) 30PIN/FFC/SHIELD/177 WX1A31F0P401
L7 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
LCD MODULE ----------
ELECTRICAL PARTS
DIGITAL MAIN CBA UNIT A31F2MMA-001
IC3001 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3002 IC 512MB DDR2 SDRAM K4T51163QJ-BCE7 NSCA0R0SM048
IC3003 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3004 IC REGULATOR BD00IA5WEFJ-E2 QSCA0T0RM233
IC3005 IC DTV-C7V R8A05011BG-U0/256FHP QSAA0R0HT057
IC3006 32MBIT C-MOS SERIAL FLASH S25FL032P0XMFI010 /S QSCA0R0FJ008
IC3007 IC LDO REGULATOR BD00IC0WEFJ/HTSOP-J8 QSCA0T0RM397
IC3008 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3009 IC RESET IC-PST8429UR QSCA0T0MM075
IC3011 IC EEPROM BU9883FV-WE2 QSCA0T0RM105
IC3013 IC SINGLE BUS BUFFER 74LVC1G126GW NSCA0TNXP004
IC3014 IC SINGLE BUS BUFFER 74LVC1G126GW NSCA0TNXP004
IC3018 IC HDMI SW TMDS351PAGR /PAG-64 NSCA0T0TY068
1/4 page
32PFL4508/F7(A31F2UT)(ME1)
IC3019 IC USB HIGH-SIDE SW AP2151WG-7/SOT25/5PI NSCA0TDES015
IC3601 IC REGULATOR AP2121AK-3.3TRE1 NSCA0TBCD026
IC3621 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3801 IC D-CLASS AUDIO POWER AMPLIFI TPA3110D2PWPR NSCA0T0TY073
IC3851 IC HEADPHONE AMP BH3547F SOP 8PIN QSZBA0TRM119
TU3901 TUNER UNIT U9001UT U9001UT
FUNCTION CBA UNIT A31F2MSW-001
IC4001 IC TOUCHSENSOR MICON NON-AUTOT CY8C20324-12LQXIT/CP NSCA0T0TY080
POWER SUPPLY CBA A31F2MPW-001
C602! SAFTY CAP. 1000PF/250V KX CA2E102MR101
C603! SAFTY CAP. 1000PF/250V KX CA2E102MR101
C604! CAP METALLIZED FILM 0.22UF/275V/K CTA224PKR001
C605 CAP ELE 330UF/200V/M/87 CEB3310S6016
C606 CERAMIC CAP. 820PF/2KV CA3D821PAN04
C607 CHIP CERAMIC CAP. B K 1800PF/50V CHD1JK30B182
C608 CHIP CERAMIC CAP.(1608) B K 0.022UF/50V CHD1JK30B223
C609 CHIP CERAMIC CAP. B K 0.068UF/50V CHD1JK30B683
C610 CHIP CERAMIC CAP.(1608) CH J 100PF/50V CHD1JJ3CH101
C614! CAP METALLIZED FILM 0.22UF/275V/K CTA224PKR001
C616! SAFTY CAP. 1000PF/250V KX CA2E102MR101
C617! CAP CERAMIC 100PF/250V KX CA2E101MR100
C622 CHIP CERAMIC CAP.(2125) B K 10UF/6.3V CHE0KK30B106
C623 CHIP CERAMIC CAP.(1608) B K 4.7UF/6.3V CHD0KK30B475
C651 CAP ELE 470UF/25V/M/85 CED4710V8006
C652 CAP ELE 470UF/25V/M/85 CED4710V8006
C653 CAP ELE 470UF/25V/M/85 CED4710V8006
C654 CAP ELE 470UF/16V/M/85 CEC4710V8006
C655 CAP ELE 470UF/16V/M/85 CEC4710V8006
C656 CAP ELE 1UF/50V/M/85 CEF1R00V8006
C660 CHIP CERAMIC CAP.(1608) B K 0.22UF/25V CHD1EK30B224
C661 CHIP CERAMIC CAP.(1608) B K 1UF/25V CHD1EK30B105
C665 CHIP CERAMIC CAP.(1608) B K 0.1UF/50V CHD1JK30B104
C666 CHIP CERAMIC CAP.(1608) B K 0.22UF/25V CHD1EK30B224
C1001 CAP ELE 330UF/25V/M/85 CED3310V8006
C1002 CHIP CERAMIC CAP.(1608) B K 1UF/25V CHD1EK30B105
C1003 CHIP CERAMIC CAP.(1608) B K 1UF/25V CHD1EK30B105
C1005 CAP ELE 47UF/100V/M/85 CEH4700V8006
C1006 CAP ELE 47UF/100V/M/85 CEH4700V8006
C1007 CHIP CERAMIC CAP.(3216) X7R K 1.0UF/100V CA2A105MR080
C1008 CHIP CERAMIC CAP.(3216) X7R K 1.0UF/100V CA2A105MR080
C1009 CHIP CERAMIC CAP.(3216) X7R K 1.0UF/100V CA2A105MR080
C1011 CHIP CERAMIC CAP.(1608) B K 1000PF/50V CHD1JK30B102
C1012 CHIP CERAMIC CAP.(1608) B K 4.7UF/6.3V CHD0KK30B475
C1013 CHIP CERAMIC CAP.(1608) B K 0.1UF/50V CHD1JK30B104
C1014 CHIP CERAMIC CAP.(1608) B K 1UF/25V CHD1EK30B105
C1017 CHIP CERAMIC CAP.(1608) B K 1000PF/50V CHD1JK30B102
C1018 CERAMIC CAP. B K 100PF/1KV CCD3AKN0B101
CN501 FPC/FFC CONNECTOR IMSA-9615S-23C-PP-A JC96J23ER009
CN601! CONNECTOR S2P3-VH (LF)(SN) JCVHC02JG002
CN1001 FPC/FFC CONNECTOR IMSA-9615S-07A-PP-A JC96J07ER007
D601 DIODE 1N5397BD NDL1001N5397
D602 DIODE 1N5397BD NDL1001N5397
D603 DIODE 1N5397BD NDL1001N5397
D604 DIODE 1N5397BD NDL1001N5397
D605 ZENER DIODE MM5Z4V3B ND1BMM5Z4V3B
D607A! ZENER DIODE SMD TFZGTR27B QD1B000TFZ27
D608! DIODE ZENER 1ZB36BB NDWZ0001ZB36
D609A DIODE SCHOTTKY SMD CES520 L3F(D QD1Z00CES520
D610 DIODE SWITCHING HSC119 TRF -E QD1Z00HSC119
D621 DIODE SWITCHING HSC119 TRF -E QD1Z00HSC119
D623 ZENER DIODE MM5Z30B ND1B0MM5Z30B
D650 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
2/4 page
