Philips 32PFL5604H/12 - Technical Specifications and Connections; 2.1 Technical Specifications

Revision List
EN 2 Q543.3E LA1.
2010-Jun-29
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
Manual xxxx xxx xxxx.1
• All chapters: added new model numbers, seeTable 2-1
.
• Chapter 9: added a block diagram for sets with Sharp
Forward Integration.
• Chapter 10: added schematic diagrams for sets with Sharp
Forward Integration.
Manual xxxx xxx xxxx.2
• All chapters: added new model number, seeTable 2-1
.
• Chapter 2, 2.3.2 Rear Connections
: added remark on
availability of Audio/Video Out on SCART 1 and 2.
• Chapter 6: updated Table 6-3
Option Code overview (for all
screensizes).
• Chapter 9: added a block diagram for 37" sets with LGD
Forward Integration.
• Chapter 10: added schematic diagrams for 37" sets with
LGD Forward Integration.
Manual xxxx xxx xxxx.3
• Chapter 5, Updated flowchart SSB replacement see
section 5.8.12 SSB Replacement
.
• Chapter 5 an 6, Updated SSB identification in 5.2.3
Customer Service Mode (CSM) as well as in see section
6.5.1 SSB identification
.
• Chapter 8: Added Figure 8-9
and Figure 8-10, Block
diagrams and pin configuration of BUF16821 and
BD8162EKV.
2. Technical Specifications and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in Table 2-1.
Here is product information available, as well as getting started,
user manuals, frequently asked questions and software &
drivers.
Table 2-1 Described Model numbers
2.2 Directions for Use
You can download this information from the following websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN Styling Published in:
32PFL5604H/12
(LGD)
P & S
3122 785 18440
32PFL5604H/12
(Sharp) 3122 785 18441
32PFL5624H/12
(LGD) 3122 785 18441
32PFL5624H/12
(Sharp) 3122 785 18441
37PFL5604H/12
(LGD) 3122 785 18442
42PFL5604H/12
(LGD) 3122 785 18440
42PFL5624H/12
(LGD) 3122 785 18441
