9.3 Wiring diagram 42" 3008 series
19450_402_130116.eps
130116
Board Level Repair See note in Chapter 6 about cable position numbers
Component Level Repair Only for authorized workshops
WIRING DIAGRAM 42" (3008 series)
LOUDSPEAKER
LOUDSPEAKER
(1185)
(1185)
LOUDSPEAKER
(1185)
LOUDSPEAKER
LOUDSPEAKER
(1185)
(1185)
LOUDSPEAKER
(1185)
MAIN POWER SUPPLY (1054)
A
CN9901
L
N
IR/LED BOARD (1056)
J
KEYBOARD CONTROL
(1057)
E
HDMI1
VGA
AUDIO PC IN
VEDIO OUT
Y/VIEDO
Pb
Pr
L
R
COMPONENT/VEDIO IN
HDMI 2
TV ANTENNA
USB
SERV.U
SSB (1053)
B
to panel
12P CN8101
CN9102
13P
12P
CN701
to panel
30P
CN403
CN016
3P
CN201
6P
4P
CN601
10P
CN401
