8-1 PL11.9TR
TROUBLESHOOTING
When buzz sound can be heard in the vicinity of power circuit.
FLOW CHART NO.4
Check if there is any short-circuit on the rectifying diode and the circuit in each rectifying ci
rcuit of the secondary side,
and service it if defective. (D1101, D1102, D1714, D1715)
The power cannot be turned on.
The fuse blows out.
FLOW CHART NO.1
FLOW CHART NO.2
Is normal state restored when once unplugged
power cord is plugged again after several seconds?
Check if there is any leak or short-circuiting on the
primary circuit component, and service it if defective.
(D1202, D1205, D1208, IC1201, T1201, R1202,
R1203, C1202)
Ye s
No
Ye s
Is the fuse (F1601) normal?
See FLOW CHART No.2 <The fuse blows out.>
No
Check if there is any leak or short-circuiting on the
primary circuit component, and service it if defective.
(D1601, IC1401, IC1702, Q1601, Q1602, Q1701,
Q1702, T1701)
No
Ye s
Is the AL+5V line voltage normal?
No
Is the PANEL+24V line voltage normal?
Ye s
Check each rectifying circuit of the secondary
circuit and service it if defective.
Check the presence that the primary component
is leaking or shorted and service it if defective.
Check the presence that the rectifying diode or circuit
is shorted in each rectifying circuit of secondary side,
and service it if defective.
After servicing, replace the fuse (F1601).
When the output voltage fluctuates.
FLOW CHART NO.3
Does the photocoupler circuit on the
secondary side operate normally?
No
Ye s
AL+5V:
Check D1103, IC1202 and their periphery circuit,
and service it if defective.
PANEL+24V:
Check D1720, IC1704 and their periphery circuit,
and service it if defective.
AL+5V:
Check D1206, D1209, D1210, D1211, IC1201, IC1202
and their periphery, circuit and service it if defective.
PANEL+24V:
Check D1703, D1704, D1710, IC1702, IC1704, Q1701,
Q1702 and their periphery, circuit and service it if
defective.
To Next Page
