PARTS LIST
[55PFL3907/F7 (Serial No.: VM1), 55PFL3907/F8 (Serial No.: XA1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1 FRONT CABINET A17RFUD 1EM029066
A3 REAR CABINET A17RFUD 1EM029067
A4 DECORATION PLATE A11R4UF 1EM125773
A6 FUNCTION BUTTON A11P4UH 1EM329857
A7 KNOB FRAME A17P5UH 1EM225743
A10 55W 5000 STAND ASSEMBLY A17R5UF 1EM027666A
A14 JACK HOLDER A A11P4UH 1EM225303
A15 JACK HOLDER B A11P4UH 1EM329877
A16 JACK LABEL A A11P4UH 1EM433958
A17 JACK LABEL B A11Q5UD 1EM435358
A18# RATING LABEL A17RFUD ----------
A20 LOGO LABEL A27UAUH ----------
A23 ENERGY GUIDE LABEL A17RFUD ----------
A26 JACK LABEL C A11P4UH 1EM433960
A27 JACK LABEL D A11P4UH 1EM433961
B1-1 GASKET A8AF0UH 1EM425861
B1-2 GASKET(60X4XT2) A01P5UF 1EM430738
B6-1 SHIELD BOX A11Q4UF 1EM027325
B6-2 FRC SHIELD BOX A11R4UF 1EM330040
B11 SHIELD PLATE A11P4UH 1EM329858
B14-1 JACK PCB HOLDER A17RFUD 1EM029069
B14-2 PCB HOLDER(U) 55W A17R5UF 1EM126275
B14-3 PCB HOLDER(D) 40W A17P5UH 1EM126034
B15 AC INLET HOLDER 5K A01P5UF 1EM327102
B17 WALL MOUNT BRACKET A17RFUD 1EM029070
B24 STAND BRACKET A17RFUD 1EM029068
CL1601 WIRE ASSEMBLY 2PIN 2PIN/180MM/WHITE
BLK
WX1A17R8-305
CL1801 WIRE ASSEMBLY 14PIN 14PIN/
115MM&170MM
WX1A17RF-1A6
CL1913 WIRE ASSEMBLY 10PIN 10PIN/1000MM WX1A17RF-1A4
CL1914 WIRE ASSEMBLY 14PIN 14PIN/370MM WX1A17RF-1A3
CL3102 WIRE ASSEMBLY 7PIN 7PIN/410MM/RED
BLACK
WX1A17R8-302
CL3801 WIRE ASSEMBLY 4PIN 4PIN/685MM&400MM WX1A17R8-304
CL3901 WIRE ASSEMBLY 51PIN 51PIN/246MM WX1A17R8-123
CL4051 WIRE ASSEMBLY 2PIN 2PIN/765MM/RED
BLACK
WX1A17RF-1A8
CL5003 WIRE ASSEMBLY 51PIN 51PIN/385MM WX1A17RF-1A1
CL5004 WIRE ASSEMBLY 41PIN 41PIN/390MM WX1A17RF-1A2
L8 SCREW P-TIGHT 3X14 WASHER HEAD+ GCHP3140
L18 SCREW S-TIGHT 3X8 WASHER HEAD+BLAC GCHS3080
L27 DOUBLE SEMS SCREW M4X6 M4X6 FPJ34060
L30 DOUBLE SEMS SCREW M8X18 M8X18 FPH38180
L37 STAND SCREW KIT A17RFUD 1ESA31988
L40 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392B
L60 SCREW P-TIGHT 3X26 WASHER HEAD+ GCJP3260
LCD-1 TFT-LCD MODULE 55W LC550WUD-SCA2 UDULCD0GS009
SP3801 SPEAKER MAGNETIC BOX 8OHM/10W SB-
05F71A
DS08050XQ013
SP3802 SPEAKER MAGNETIC BOX 8OHM/10W SB-
05F71A
DS08050XQ013
TH3104 THERMAL SHEET TMS-14-20 12X12 XK10000X4011
TH5001 THERMAL SHEET TMS-L-2 25X25HC XK10000X4007
USB-1 WIRELESS LAN ADAPTOR AW-NU138/2-
11380-B2H
UWLUSBAZW002
PACKING
S1 CARTON(U) A17RFUD 1EM332457A
S2 CARTON(L) A17RFUD 1EM332917
S3 STYROFOAM TOP A17RFUD 1EM029071
S4 STYROFOAM BOTTOM A17RFUD 1EM029072
S6 SET BAG(1500X1100) A11R5UD 1EM332440
S7 SERIAL NO. LABEL A01PBUH ----------
S13 CARTON LABEL A17RFUD ----------
ACCESSORIES
AC601# CORD W/O A GND WIRE UL/CSA/ 162/NO/
BLACK
WAV0162LW001
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# OWNERS MANUAL A17RFUD 1EMN29479A
X3 REMOTE CONTROL UNIT YKF255-008 URMT42JHG003
X4 BATTERY R03-B500/01S XB0M451CZB01
X6 QUICK START GUIDE A17RFUD 1EMN29480A
X7 REGISTRATION CARD(PHILIPS) A11P4UH 1EMN27321
X9 BROCHURE (PHILIPS) A01N2UH 1EMN26419
X12 CABLE MANAGEMENT TIE(BLACK) A01F2UH 1EM431197
X17 VUDU SHEET E5S20UD 1VMN30133
Ref. No. Description Part No.
