2012/04/20 14-2 A17RFEL.fm
Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
FRC CBA UNIT
DIGITAL ASSEMBLY
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
FRC CBA UNIT A11R5MFR-001
Ref. No. Description Part No.
DIGITAL ASSEMBLY
Consists of the following
A17RFMMA-001
DIGITAL MAIN CBA UNIT A17RFMMA-001-DM
FUNCTION CBA UNIT A17RFMMA-001-FN
IR SENSOR CBA UNIT A17RFMMA-001-IR
Ref. No. Description Part No.
POWER SUPPLY CBA
Consists of the following
A17RFMPW-001
CAPACITORS
C1101 ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C1102 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
C1104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1201 ELECTROLYTIC CAP 22µF/200V CE2DMZNDL220
C1202 CAP CERAMIC HV 1000pF/1KV B K CA3A102TE006
C1203 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1204 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1205 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1206 CHIP CERAMIC CAP. B K 330pF/50V CHD1JK30B331
C1208 CAP CERAMIC SL J 15pF/2KV CCD3DJNSL150
C1210 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1214# CAP CERAMIC 470pF/250V KX CA2E471MR100
C1250 ELECTROLYTIC CAP. 470µF/35V M CE1GMZNDL471
C1401 CHIP CERAMIC CAP. B K 1200pF/50V CHD1JK30B122
C1402 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C1403 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1404 CHIP CERAMIC CAP.(1608) B K 2.2µF/10V CHD1AK30B225
C1405 CHIP CERAMIC CAP. B K 1200pF/50V CHD1JK30B122
C1406 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1407 CHIP CERAMIC CAP. B K 1200pF/50V CHD1JK30B122
C1408 ELECTROLYTIC CAP. 33µF/50V M CE1JMASDL330
C1409 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1410 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C1412 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1413# CAP CERAMIC 470pF/250V KX CA2E471MR100
C1414 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1415 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C1416 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C1417 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1601# CAP METALIZED FILM 1.0µF/310V /K/LE-MX CTA1050DC001
C1602# CAP METALIZED FILM 0.1µF/310V /K/LE-MX CTA1040DC001
C1605# CAP CERAMIC 470pF/250V KX CA2E471MR100
C1606# CAP CERAMIC 470pF/250V KX CA2E471MR100
C1607# CAP METALIZED FILM J1.0µF/630V/J/MPEF CA2K105DT048
C1610# CAP METALIZED FILM 0.22µF/310V /K/LE-MX CTA2240DC001
C1612 CAP ELECTROLYTIC 270µF/400V/M/30/30 CA2H271DYG10
C1618 CERAMIC CAP. BL 1500pF/2KV CA3D152XF003
C1701 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1702 CERAMIC CAP. RB 330pF/2KV CA3D331TE006
C1703 CERAMIC CAP. RB 330pF/2KV CA3D331TE006
C1704 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C1705 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C1706 CERAMIC CAP. B K 100pF/1KV CCD3AKD0B101
C1707 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1708 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1709 CHIP CERAMIC CAP. B K 330pF/50V CHD1JK30B331
C1710 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1711 CHIP CERAMIC CAP.(1608) B K 0.47µF/16V CHD1CK30B474
C1712 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1713 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C1714 CAP METALIZED FILM J0.039µF/630V/J/MPEF CA2K393DT045
C1715 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C1716 ELECTROLYTIC CAP. 33µF/50V M CE1JMASDL330
C1717 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1718 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1719 ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASDL4R7
C1720 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C1721 ELECTROLYTIC CAP. 47µF/50V M CE1JMASDL470
C1722 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1725 ELECTROLYTIC CAP. 2200µF/35V M CE1GMZNDL222
C1726 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1727 ELECTROLYTIC CAP. 2200µF/35V M CE1GMZNDL222
C1728 ELECTROLYTIC CAP. 470µF/35V M CE1GMZNDL471
C1731 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1732 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1733 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1734 CAP CERAMIC HV 1000pF/1KV B K CA3A102TE006
C1735 CAP CERAMIC HV 1000pF/1KV B K CA3A102TE006
C1736 ELECTROLYTIC CAP. 2200µF/16V M CE1CMZNDL222
C1737 ELECTROLYTIC CAP. 2200µF/16V M CE1CMZNDL222
C1739 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1741 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1742 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1743 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1804 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
CONNECTORS
CN1601# CONNECTOR B2P3-VH(LF)(SN) J3VH020JG001
CN1801 CONNECTOR PRINT OSU B14B-PH-K-
S(LF)(SN)
J3PHC14JG029
CN1913 PH CONNECTOR TOP 10P B10B-PH-K-
S(LF)(SN)
J3PHC10JG029
Ref. No. Description Part No.
