2012/04/20 14-3 A17RFEL.fm
CN1914 CONNECTOR PRINT OSU B14B-PH-K-
S(LF)(SN)
J3PHC14JG029
DIODES
D1101 DIODE FR104-B NDLZ000FR104
D1102 SCHOTTKY BARRIER DIODE SB240-B/P NDWZ000SB240
D1103 SHUNT REGULATOR KIA2431AP-AT/P NSZBA0TJY054
D1202# DIODE GENERAL PURPOSE 1N5406-BU NDLZ1N5406BU
D1205 DIODE SCHOTTKY BARRIER 1H8-A2 NDTZ0001H8A2
D1206 DIODE FR104-B NDLZ000FR104
D1207 DIODE ZENER 33BSB-T26 NDTB033BST26
D1207A ZENER DIODE SMD TFZGTR33B QD1B000TFZ33
D1209# DIODE ZENER 39BSB-T26 NDTB039BST26
D1209A ZENER DIODE SMD TFZGTR39B QD1B000TFZ39
D1210# DIODE ZENER 39BSB-T26 NDTB039BST26
D1210A ZENER DIODE SMD TFZGTR39B QD1B000TFZ39
D1211# DIODE ZENER 39BSB-T26 NDTB039BST26
D1211A ZENER DIODE SMD TFZGTR39B QD1B000TFZ39
D1215 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1250 DIODE FAST RECOVERY FR103-B/P NDWZ0FR103BP
D1252 DIODE ZENER 24BSB-T26 NDTB024BST26
D1252A ZENER DIODE SMD TFZGTR24B QD1B000TFZ24
D1401 DIODE ZENER 16BSB-T26 NDTB016BST26
D1401A ZENER DIODE SMD TFZGTR16B QD1B000TFZ16
D1402 DIODE ZENER 24BSB-T26 NDTB024BST26
D1402A ZENER DIODE SMD TFZGTR24B QD1B000TFZ24
D1601# DIODE BRIDGE D10XB60-7000 QDWZ0D10XB60
D1603 DIODE ZENER 27BSB-T26 NDTB027BST26
D1603A ZENER DIODE SMD TFZGTR27B QD1B000TFZ27
D1604 DIODE FAST RECOVERY 30PFB60 QDWZ030PFB60
D1605 DIODE ZENER 27BSB-T26 NDTB027BST26
D1605A ZENER DIODE SMD TFZGTR27B QD1B000TFZ27
D1606 DIODE FAST RECOVERY 30PFB60 QDWZ030PFB60
D1703 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1704 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1705# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1706 SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1707 SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1708 DIODE ZENER 4V7BSB-T26 NDTB4R7BST26
D1708A ZENER DIODE SMD TFZGTR4.7B QD1B00TFZ4R7
D1710 DIODE ZENER 33BSB-T26 NDTB033BST26
D1710A ZENER DIODE SMD TFZGTR27B QD1B000TFZ27
D1712 DIODE ZENER 18BSB-T26 NDTB018BST26
D1712A ZENER DIODE SMD TFZGTR18B QD1B000TFZ18
D1714 DIODE SILICON YG865C08RSC-P QDWZG865C08R
D1715 DIODE SILICON YG865C08RSC-P QDWZG865C08R
D1720 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
D1728 DIODE ZENER 27BSD-T26 NDTD027BST26
D1728A ZENER DIODE SMD TFZGTR27D QD1D000TFZ27
D1729 DIODE ZENER 16BSB-T26 NDTB016BST26
D1729A ZENER DIODE SMD TFZGTR16B QD1B000TFZ16
D1735 SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D1736 SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D1737 SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D1738 SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
ICS
IC1201# IC SWITCHING POWER SUPPLY
MIP2F30MSSCF DIP7-A1
QSCA0S0MS012
IC1202# PHOTO COUPLER PS2561L1-1-A-V(L) QPEL561L11AV
IC1401# IC DUAL-PHASE PFC CONTROLLER
HPA00651DR/SOIC
NSCA0T0TY015
IC1702# IC 0V-SWITCHING RESONANT CONVE
TEA1611T/N1.518
NSCA0TNXP002
IC1703# PHOTO COUPLER PS2561L1-1-A-V(L) QPEL561L11AV
IC1704# PHOTO COUPLER PS2561L1-1-A-V(L) QPEL561L11AV
Ref. No. Description Part No.
IC1705# PHOTO COUPLER PS2561L1-1-A-V(L) QPEL561L11AV
COILS
L1601# COIL LINE FILTER ST1101ET28H-016/14MH LLEG0Z0Y2032
L1602# COIL LINE FILTER ST1101ET28H-016/14MH LLEG0Z0Y2032
L1603# COIL EF 11727 LLEE0Z0KT003
L1604# COIL EF 11727 LLEE0Z0KT003
TRANSISTORS
Q1201 CHIP TRANSISTOR 2SC2412K T146S QQ1S2SC2412K
Q1202 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q1401 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q1402 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q1403 CHIP TRANSISTOR 2SC2412K T146S QQ1S2SC2412K
Q1404 CHIP TRANSISTOR 2SC2412K T146S QQ1S2SC2412K
Q1601# FET MOS 2SK3561(Q) IDSS100UA QFWZ2SK3561Q
Q1602# FET MOS 2SK3561(Q) IDSS100UA QFWZ2SK3561Q
Q1701# MOS FET 2SK3568(Q) QQQZ02SK3568
Q1702# MOS FET 2SK3568(Q) QQQZ02SK3568
Q1703 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q1704 CHIP TRANSISTOR 2SC2412K T146S QQ1S2SC2412K
Q1705 CHIP TRANSISTOR 2SC2412K T146S QQ1S2SC2412K
Q1706 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q1707 CHIP TRANSISTOR 2SC2412K T146S QQ1S2SC2412K
Q1708 CHIP TRANSISTOR 2SC2412K T146S QQ1S2SC2412K
Q1709 CHIP TRANSISTOR 2SC2412K T146S QQ1S2SC2412K
RESISTORS
R1101 RES CHIP 1608 1/10W F 68.0k Ω RTW6802HH008
R1102 RES CHIP 1608 1/10W F 51.1k Ω RTW5112HH008
R1103 RES CHIP 1608 1/10W F 47.0k Ω RTW4702HH008
R1104 RES CHIP 1608 1/10W J 1.0k Ω RRXA102HH013
R1105 RES CHIP 1608 1/10W J 390 Ω RRXA391HH013
R1110 RES CHIP 1608 1/10W J 3.3k Ω RRXA332HH013
R1201# METAL OXIDE FILM RES. 2W J 1 Ω RN021R0ZU001
R1202 RES CARBON FILM T 1/4W J 100k Ω RCX4104T1001
R1203 RES CARBON FILM T 1/4W J 100k Ω RCX4104T1001
R1204 RES CARBON FILM T 1/4W J 100 Ω RCX4101T1001
R1205 RES CHIP 1608 1/10W J 470k Ω RRXA474HH013
R1206 RES CHIP 1608 1/10W J 36k Ω RRXA363HH013
R1209 RES CHIP 1608 1/10W J 6.8k Ω RRXA682HH013
R1210 RES CHIP 1608 1/10W J 47k Ω RRXA473HH013
R1214 RES CARBON FILM T 1/4W J 2.2 Ω RCX42R2T1001
R1216 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
R1226 RES CHIP 1608 1/10W J 4.7k Ω RRXA472HH013
R1401 RES CHIP 3216 1/4W F 825k Ω RTC8253HH020
R1402 RES CHIP 3216 1/4W F 825k Ω RTC8253HH020
R1403 RES CHIP 3216 1/4W F 619k Ω RTC6193HH020
R1404 RES CHIP 3216 1/4W F 619k Ω RTC6193HH020
R1405 RES CHIP 1608 1/10W F 51.1k Ω RTW5112HH008
R1406 RES CHIP 1608 1/10W J 120k Ω RRXA124HH013
R1407 RES CHIP 1608 1/10W F 2.74k Ω RTW2741HH008
R1408 RES CHIP 1608 1/10W F 33.2k Ω RTW3322HH008
R1409 RES CHIP 1608 1/10W J 5.6k Ω RRXA562HH013
R1410 RES CARBON FILM T 1/4W J 47 Ω RCX4470T1001
R1411 RES CARBON FILM T 1/4W J 100 Ω RCX4101T1001
R1412 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1413 RES CHIP 1608 1/10W J 4.7k Ω RRXA472HH013
R1414 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R1415 RES CHIP 1608 1/10W J 4.7k Ω RRXA472HH013
R1416 RES CHIP 1608 1/10W J 39k Ω RRXA393HH013
R1417 RES CHIP 3216 1/4W F 100k Ω RTC1003HH020
R1418 RES CHIP 3216 1/4W F 100k Ω RTC1003HH020
R1419 RES CHIP 3216 1/4W F 100k Ω RTC1003HH020
R1420 RES CHIP 1608 1/10W F 26.7k Ω RTW2672HH008
Ref. No. Description Part No.
