Alignments
EN 40 QM15.2E LA6.
2015-Sep-30
back to
div.table
This group setting of colour temperature will be applied
automatically to the TV / VGA / HDMI / AV sources.
Note: The information of the RGB value is only for reference,
the specific value is based on model adjustment.
6.4 Option Settings
6.4.1 Introduction
The microprocessor communicates with a large number of I
2
C
ICs in the set. To ensure good communication and to make
digital diagnosis possible, the microprocessor has to know
which ICs to address. The presence / absence of these
MT5561 ICs is made known by the option codes.
Notes:
• After changing the option(s), save them by pressing the OK
button on the RC before the cursor is moved to the left,
select STORE and press OK on the RC.
• The new option setting is only active after the TV is
switched “off” / “stand-by” and “on” again with the mains
switch (the NVM is then read again).
6.4.2 Option Code Overview
Enter SAM mode to check the option codes. they could be
edited in the NVM.
6.4.3 Display Code Overview
Press the following key sequence on a standard RC
transmitter: “062598” directly followed by MENU and “xxx”,
where “xxx” is a 3 digit decimal value of the panel type: see
column “Display Code” in back to div.table 6-3
. After resetting
the Display Code, restart the set immediately.
Table 6-3 Display code overview
Warm (6500K) 32PFH5500/88 127 112 101
32PFK5500/12 126 111 100
32PFT5500/12 125 110 101
32PFH6500/88 127 108 71
32PFK6500/12 127 108 70
32PFT6500/12 127 107 71
32PFT6500/60 127 108 71
39PFH5500/88 127 112 106
39PFK5500/12 127 112 105
39PFT5500/12 127 113 107
40PFH5500/88 127 110 95
40PFK5500/12 127 112 97
40PFT5500/12 127 111 96
40PUK6400/12 127 99 97
40PUH6400/88 127 98 97
40PUT6400/12 126 97 96
40PUT6400/60 127 97 97
40PFH6510/88 127 91 54
40PFK6510/12 127 90 53
40PFT6510/12 127 91 53
40PFT6510/60 127 90 54
40PFK6540/12 125 92 51
40PFH6550/88 126 90 54
40PFK6550/12 127 91 55
40PFT6550/12 127 91 54
40PFK6560/12 127 91 52
40PFK6580/12 126 90 51
48PFH5500/88 125 95 95
48PFK5500/12 123 96 94
48PFT5500/12 122 95 92
50PUK6400/12 127 91 54
50PFH6510/88 118 98 79
50PFK6510/12 117 98 79
50PFT6510/12 116 97 79
50PFT6510/60 118 96 78
50PFK6540/12 117 95 77
50PFH6550/88 118 97 76
50PFK6550/12 114 98 77
50PFT6550/12 119 96 78
50PFK6560/12 114 98 77
50PFK6580/12 119 96 78
55PFH5500/88 127 91 54
55PFK5500/12 125 91 53
55PFT5500/12 127 90 52
55PUH6400/88 126 90 54
55PUK6400/12 124 91 53
55PUT6400/12 125 92 54
55PFH6510/88 120 101 91
55PFK6510/12 122 102 93
55PFT6510/12 121 104 93
55PFT6510/60 122 101 92
55PFK6540/12 123 101 91
55PFH6550/88 121 104 91
55PFK6550/12 127 101 95
55PFT6550/12 125 105 92
55PFK6560/12 121 104 91
55PFK6580/12 125 103 92
65PFH6520/88 127 91 54
65PFK6520/12 126 90 54
65PFT6520/12 125 91 53
65PFT6520/60 127 92 52
Picture mode Screen size
Colour temperature
Red Green Blue
CTN_ALT BOM# Panel Type Display Code
32PFH5500/88 TPT315B5-EUJFFE 211
32PFK5500/12 TPT315B5-EUJFFE 211
32PFT5500/12 TPT315B5-EUJFFE 211
32PFH6500/88 TPT315B5-EUJFFE S1M 221
32PFK6500/12 TPT315B5-EUJFFE S1M 221
32PFT6500/12 TPT315B5-EUJFFE S1M 221
32PFT6500/60 TPT315B5-EUJFFE S1M 221
39PFH5500/88 TPT400LA-J6PE1 212
39PFK5500/12 TPT400LA-J6PE1 212
39PFT5500/12 TPT400LA-J6PE1 212
40PFH5500/88 TPT400LA-HM10.S S01C 213
40PFH5500/88 TPT400LA-HN02.S SS01C 034
40PFK5500/12 TPT400LA-HM10.S S01C 213
40PFK5500/12 TPT400LA-HN02.S SS01C 034
40PFT5500/12 TPT400LA-HM10.S S01C 213
40PFT5500/12 TPT400LA-HN02.S SS01C 034
40PUK6400/12 TPT400LA-K1QS1.N 231
40PUK6400/12 TPT400UA-DJ1QS5.N SM1 035
40PUH6400/88 TPT400LA-K1QS1.N 231
40PUH6400/88 TPT400UA-DJ1QS5.N SM1 035
40PUT6400/12 TPT400LA-K1QS1.N 231
40PUT6400/12 TPT400UA-DJ1QS5.N SM1 035
40PUT6400/60 TPT400LA-K1QS1.N 231
40PUT6400/60 TPT400UA-DJ1QS5.N SM1 035
40PFH6510/88 TPT400LA-HF07.S 217
40PFK6510/12 TPT400LA-HF07.S 217
40PFT6510/12 TPT400LA-HF07.S 217
40PFT6510/60 TPT400LA-HF07.S 217
40PFK6540/12 TPT400LA-HF07.S 217
40PFH6550/88 TPT400LA-HF07.S 217
40PFK6550/12 TPT400LA-HF07.S 217
40PFT6550/12 TPT400LA-HF07.S 217
40PFK6560/12 TPT400LA-HF07.S 217
40PFK6580/12 TPT400LA-HF07.S 217
