Page #22 background imageLoading...
Page #22 background image
Subtitles Language
If none of the preferred subtitle languages are
available, you can select another subtitle language if
available. If no subtitle languages are available, you
cannot select this option.
To read more information, in Help, press the colour
key Keywords and look up Subtitle Language.
Audio Language
If none of the preferred audio languages are
available, you can select another audio language if
available. If no audio languages are available, you
cannot select this option.
To read more information, in Help, press the colour
key Keywords and look up Audio Language.
Dual I-II
If an audio signal contains two audio languages but
one language or both has no language indication, this
option is available.
Common Interface
If prepaid premium content is available from a CAM,
you can set the provider settings with this option.
Mono / Stereo
You can switch the sound of an analogue channel to
Mono or Stereo.
To switch to Mono or Stereo…
Tune to an analoge channel.
1 - Press OPTIONS, select Mono/Stereo and
press (right).
2 - Select Mono or Stereo and press OK.
3 - Press (left) repeatedly if necessary, to close
the menu.
Status
Select Status to view technical information on the
channel or a connected device you are watching.
HbbTV on This Channel
If you want to avoid access to HbbTV pages on a
specific channel, you can block the HbbTV pages for
this channel only.
1 - Tune to the channel of which you want to block
the HbbTV pages.
2 - Press OPTIONS and select HbbTV on this
channel and press (right).
3 - Select Off and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
To block HbbTV on TV completely…
(Home) > Settings > All settings > Channels
> HbbTV > Off
Universal Access
Only available when Universal access set to On.
(Home) > Settings > All settings > Universal
access > Universal access > On.
To read more information, in Help, press the colour
key Keywords and look up Universal Access.
Share
Enables the user to communicate his activity with his
social networks (such as Twitter or email).
Video Selection
Digital TV channels can offer multi video signals (multi-
feed broadcast), different camera viewpoints or
angles of the same event or different programmes on
one TV channel. The TV shows a message if any such
TV channels are available.
7.3
Channel List
Open Channel List
To open the current channel list…
1 - Press , to switch to TV.
2 - Press LIST to open the current channel list.
3 - Press OPTIONS > Select channel list, and
select one channel list you want to watch.
4 - Press LIST again to close the channel list.
22

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS6503 and is the answer not in the manual?

Philips 55PUS6503 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Peak luminance ratio65 %
Supported video modes2160p
Display diagonal (metric)139 cm
Screen format adjustments16:9
Supported graphics resolutions3840 x 2160
Motion interpolation technology-
RMS rated power20 W
DVI portNo
HDMI ports quantity3
DVI-D ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio Return Channel (ARC)Yes
Component video (YPbPr/YCbCr) in1
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)86 W
Package depth160 mm
Package width1360 mm
Package height860 mm
Package weight20500 g
USB ports quantity2
Annual energy consumption126 kWh
Product colorBlack
Mercury content0 mg
Panel mounting interface300 x 200 mm
Processor cores4
Audio formats supportedAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, JPEG, PNG, PNS
Video formats supportedAVI, HEVC, MKV, MPEG1, MPEG2, MPEG4, VC-1, VP9, WMV9
Subtitle formats supportedSMI, SRT, SUB, SUP, TXT
Operating temperature (T-T)5 - 35 °C
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-S2, DVB-T, DVB-T2, DVB-T2 HD, ISDB-C, ISDB-S
Video appsYouTube
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Weight and Dimensions IconWeight and Dimensions
Stand width768 mm
Depth (with stand)227.4 mm
Height (with stand)742.2 mm
Weight (with stand)15300 g
Depth (without stand)81.4 mm
Width (without stand)1244.2 mm
Height (without stand)719 mm
Weight (without stand)15100 g
