Philips AZ 1505 - Page 26

12 - 3
ELECTRICAL PARTSLIST - TUNER PART
- RESISTORS - - IC & TRANSISTORS -
3189 4822 051 30223 22K 5% 0,062W 7101 9351 740 80557 TEA5757H/V1
3190 4822 051 30103 10K 5% 0,062W 7102 4822 130 42131 BF550
3191 4822 051 30472 4,7K 5% 0,062W 7104 4822 130 40855 BC337
3192 4822 051 30105 1M 5% 0,062W 7105 4822 130 40855 BC337
3193 4822 051 30222 2,2K 5% 0,062W 7109 4822 130 60373 BC856B
3194 4822 117 13632 100K 1% 0,62W 7111 5322 130 42755 BC847C
3195 4822 051 30474 470K 5% 0,062W 7122 5322 130 42755 BC847C
3196 4822 051 30103 10K 5% 0,062W 7124 5322 130 42755 BC847C
4104 4822 051 30008 0R J UMPER 7180 4822 130 60373 BC856B
4105 4822 051 30008 0R J UMPER 7181 5322 130 42755 BC847C
4106 4822 051 30008 0R J UMPER 7182 5322 130 42755 BC847C
4107 4822 051 30008 0R J UMPER 7183 5322 130 42755 BC847C
4108 4822 051 30008 0R J UMPER
4109 4822 051 30008 0R J UMPER
4110 4822 051 30008 0R J UMPER Note: Only these parts mentioned in the list are
normal service parts.
- COILS & FILTERS
1106 3140 114 50050 FERRITE BAR D10X80MM
1106 2422 549 44211 FERRITE BAR 5X13X55
5104 4822 157 11269 COIL MW ANT. (3-BAND)
5104 2422 536 00364 COIL MW ANT. (2-BAND)
5105 4822 157 11271 COIL LW ANT.
5109 4822 242 70665 SFE10,7MS3-A
5110 4822 242 70665 SFE10,7MS3-A
5111 2422 549 44023 IND VAR 450KHZ
5112 4822 157 70302 F7MCS-12216N
5114 4822 157 70302 F7MCS-12216N
5119 4822 157 11443 Coil 2,4 H
5121 4822 242 10261 T6252F00 (75KHZ)
5122 2422 549 44108 COIL AM OSC.
5123 2422 549 44108 COIL AM OSC.
5130 4822 157 11843 COIL FM
5131 4822 157 11843 COIL FM
- DIODES -
6103 5322 130 34337 BAV99
6105 4822 130 83075 HN1V02H-B
6120 4822 130 11397 BAS316
6130 4822 130 82833 1SV228
6131 4822 130 82833 1SV228
6181 5322 130 34337 BAV99
6182 4822 130 11397 BAS316
6183 9340 386 90115 BZX284-C11
