ELECTRICAL PARTSLIST
- MISCELLANEOUS - - COILS & FILTERS -
J502 9965 000 20543 STEREO EARPHONE L8 9965 000 20550 2,7µH SMD COIL
9965 000 20544 EARPHONE
DOOR 9965 000 09617 TACT-SWITCH
SW50 9965 000 20555 SWITCH
SW1 9965 000 20556 SWITCH - DIODES -
9965 000 20557 TACT-SWITCH ZD1 5322 130 31504 BZX79-B3V3
4822 158 60645 FERROCEPTOR D1 4822 130 30621 1N4148
1707 4822 277 11504 PUSH-SWITCH D2 4822 130 30621 1N4148
!
9965 000 08577 AC SOCKET D4 4822 130 30621 1N4148
4822 277 30971 SWITCH D5 4822 130 30621 1N4148
!
9965 000 20564 TRANSFORMER AC120/230V D701 4822 130 30621 1N4148
!
9965 000 20566 TRANSFORMER AC230V X1 9965 000 20552 8,4672 MHZ CRYSTAL
!
2422 070 98151 MAINSCORD EUR 1M5 BK BX2 9965 000 14271 CRYSTAL 27MHZ
!
9965 000 12162 AC CORD SET (SAA) ZD60 4822 130 10493 DIODE 8,2V
9965 000 20565 LOUDSPEAKER D601 5322 130 34574 1N4004G
F601
!
4822 070 32001 FUSE D602 5322 130 34574 1N4004G
IR1 9965 000 20561 REMOTE RECEIVER D603 5322 130 34574 1N4004G
D604 5322 130 34574 1N4004G
D606 5322 130 34574 1N4004G
- CAPACITORS & RESISTORS - D7 5322 130 34574 1N4004G
9965 000 20563 PVC 20P-160P/20X2 D6 4822 130 30621 1N4148
VR1 9965 000 20558 VR B50K D607 4822 130 30621 1N4148
RB1 9965 000 20553 100OHM X4 RESISTOR ARRAY ZD30 9965 000 16799 ZENER DIODE 2,4V 1/2W
RB2 9965 000 20553 100OHM X4 RESISTOR ARRAY D301 4822 130 30621 1N4148
RB5 9965 000 20553 100OHM X4 RESISTOR ARRAY D302 4822 130 30621 1N4148
RB6 9965 000 20554 10 KOHM X4 RESISTOR ARRAY 6704 4822 130 30621 1N4148
- COILS & FILTERS - - IC & TRANSISTORS -
9965 000 20560 LCD DISPLAY Q1 9965 000 16236 PBSS4140T
5701 4822 157 10371 COIL Q5 9965 000 16236 PBSS4140T
T301 9965 000 16786 MW OSC,COIL 843744 Q11 9965 000 16236 PBSS4140T
T302 9965 000 16787 IFT MW 843745 Q12 9965 000 16236 PBSS4140T
T303 4822 157 10689 FM DET COIL Q14 9965 000 16236 PBSS4140T
9965 000 16788 MW ANT,COIL 95T:15T Q15 9965 000 16236 PBSS4140T
L303 9965 000 11817 FM COIL 3-1/2T Q8 9965 000 16236 PBSS4140T
L302 4822 157 71567 2,5T Q2 9965 000 16235 PBSS5140T
L301 9965 000 20562 10µH FIXED INDUCTOR U11 9965 000 14730 SPCA711A
CF30 9965 000 16789 LT10,7MS CER,FILTER U5 9965 000 20545 SPCA718A
T304 9965 000 16790 BAND PASS FILTER U9 9965 000 16777 MM1469A
CF30 9965 000 16797 CERAMIC FILTER SFU465B U3 9965 000 20546 AT27C040-70PC
L1 9965 000 20549 10µH CHIP INDUCTOR U13 9965 000 20547 SA57004-50GW
L13 9965 000 20549 10µH CHIP INDUCTOR U8 9965 000 20547 SA57004-50GW
L14 9965 000 20549 10µH CHIP INDUCTOR U7 9965 000 20548 SA57255-33GW
L15 9965 000 20549 10µH CHIP INDUCTOR U10 9965 000 16922 SAA7824HL
L3 9965 000 20549 10µH CHIP INDUCTOR U1 9965 000 13432 WM8725
L5 9965 000 20549 10µH CHIP INDUCTOR D3 9965 000 20551 SM5817
L9 9965 000 20549 10µH CHIP INDUCTOR IC30 9965 000 16785 KA22902
L11 9965 000 20550 2,7µH SMD COIL 9965 000 10667 HT1621
