Philips AZ1065 - Electrical Parts List - Recorder Board; Recorder Board Component Breakdown

13-7
PCS 104 388
ELECTRICAL PARTSLIST - RECORDER BOARD
- CAPACITORS - - RESISTORS -
2703 482212481151 22µF 50V 3727 482211652256 2K2 5% 0,5W
2704 482212481151 22µF 50V 3730 482211683868 150R 5% 0,5W
2706 482212440433 47µF 20% 25V 3731 482211652291 56K 5% 0,5W
2707 482212440196 220µF 20% 16V 3732 482211652176 10R 5% 0,5W
2708 482212440433 47µF 20% 25V 3733 482211130893 4M7 5% 0,2W
2709 482212440433 47µF 20% 25V 3734 482205021003 10K 1% 0,6W
2710 482212441584 100µF 20% 10V 3743 482211683883 470R 5% 0,5W
2711 482212481151 22µF 50V 3744 482211683883 470R 5% 0,5W
2712 482212612878 1,5nF 10% 16V 3747 482211683868 150R 5% 0,5W
2714 482212612878 1,5nF 10% 16V 3748 482211683883 470R 5% 0,5W
2715 482212151387 10nF 20% 16V 3749 482211683883 470R 5% 0,5W
2716 482212612882 100nF +80-20% 50V 3761 482211652289 5K6 5% 0,5W
2719 482212613098 5,6nF 20% 16V 3762 482211652289 5K6 5% 0,5W
2721 482212612878 1,5nF 10% 16V
2722 482212151387 10nF 20% 16V - COIL -
2723 482212612882 100nF +80-20% 50V 5701 482215710371 Coil 100kHz
2726 482212613098 5,6nF 20% 16V
2727 482212612878 1,5nF 10% 16V - DIODE -
2728 482212611714 4,7nF 20%
2729 482212611714 4,7nF 20% 6704 482213030621 Diode 1N4148
2730 202030090561 1,2nF 10% - IC & TRANSISTORS -
2732 482212210577 3,3nF 10% 16V
2733 482212151387 10nF 20% 16V 7702 482213040981 Trans BC337-25
2738 482212151387 10nF 20% 16V 7705 482220917498 IC AN7323
2739 482212151387 10nF 20% 16V
1707 482227711504 Push Switch
2750 482212613098 5,6nF 20% 16V
- MISCELLANEOUS -
2751 482212613098 5,6nF 20% 16V
1725 482226511207 Connector 6P
- RESISTORS -
Note: :
Only these parts mentioned in the list are
3701 482211652175 100R 5% 0,5W normal service parts.
3703 482211683868 150R 5% 0,5W
3704 482211683872 220R 5% 0,5W
3706 482211652272 330K 5% 0,5W
3707 482211652285 470K 5% 0,5W
3710 482211652264 27K 5% 0,5W
3712 482211652238 12K 5% 0,5W
3713 482211683868 150R 5% 0,5W
3714 482211683872 220R 5% 0,5W
3716 482211652272 330K 5% 0,5W
3719 482211652264 27K 5% 0,5W
3720 482211652238 12K 5% 0,5W
3722 482211652257 22K 5% 0,5W
3723 482211652257 22K 5% 0,5W
3726 482211652256 2K2 5% 0,5W
