Philips AZ1065 - Electrical Parts Lists; Power Board and Miscellaneous Parts

PCS 107 135
13-8
ELECTRICAL PARTSLIST - POWER BOARD
- CAPACITORS -
2028 4822 126 12882 100nF +80-20% 50V
2029 4822 126 12882 100nF +80-20% 50V
2030 5322 121 42386 100nF 5% 63V
2031 4822 126 12882 100nF +80-20% 50V
2032 4822 126 12882 100nF +80-20% 50V
- DIODES -
6004 4822 130 31878 Diode 1N4003G
6005 4822 130 31878 Diode 1N4003G
6006 4822 130 31878 Diode 1N4003G
6007 4822 130 31878 Diode 1N4003G
- MISCELLANEOUS -
1012 4822 265 20287 Socket Mains
Note: Only these parts mentioned in the list are
normal service parts.
ELECTRICAL PARTSLIST - MISCELLANEOUS
1007 4822 240 10248 Speaker 4 Ohm 6W
1008 4822 240 10248 Speaker 4 Ohm 6W
1009 2422 264 00423 Piezo Speaker
1010 2422 264 00423 Piezo Speaker
1011 3140 113 22610 Volt Selector (For -/01/11/16)
5001 3140 118 32850 Transformer (For -/00/05/10/14)
5001 3140 118 33060
Transformer (For -/01/11/16)
5001 3140 118 32860 Transformer (For -/17)
8002 3140 110 21680 FFC Foil 6P
8003 3139 110 34590 FFC Foil 6P
8007 4822 320 12243 Flex Cable 6P
8015 3140 110 21690 FFC Foil 9P
8016 3139 110 34420 FFC Foil 5P
8018 3140 110 21720 FFC Foil 8P
8021 3140 110 21670 FFC Foil 4P
8800 4822 320 12178 Flexible Foil 15P
4822 276 13963 CD Door Switch
Note: Only these parts mentioned in the list are
normal service parts.
- MISCELLANEOUS -
