6
Connect speakers
Note
Use speakers with an impedance of 2 to 8 ohm •
(4 to 8 ohm when used as a bridged amplier).
Match the “left”, “right”, “+” and “-” terminals
•
correctly. Revised polarity may degrade sound
quality.
Option 1: Mono bridged mode: connect
1 speaker
Option 2: Stereo mode: connect 2 speakers
3 Installation
Installation
You can mount the amplier either under a seat
or on the rear tray.
Note
To avoid interference, do not place the •
amplier too close to the car audio or antenna.
The supplied mounting screws are 25mm long.
•
Make sure that the mounting board is thicker
than 25mm.
1 Place the unit on the location for
installation.
2 Mark the positions of the four screw
holes.
3 Drill the holes with driller of
approximately 4mm in diameter.
4 Mount the unit with the supplied screws.
EN
