Philips car power amplifier - Connecting Power Supply

8
Connect power
1
Make the power connection as illustrated below:
Connect the ground wire from the car to the • GND socket.
Connect the remote wire from the car audio to the • REM socket.
√ With this connection, you can turn on/off the amplier with the car audio.
Connect the power wire from the car battery to the• +12V socket.
Tip
If your car audio does not have remote output, connect the remote input terminal (REM) to the accessory •
power supply.
to a metal point of the car
Car audio unit
Remote output
Fuse (60 A)
+12 V car battery
less than 450 mm (18 in)
