Connect car audio
Option 1: High level input connection
Connect the amplier to your car audio with the supplied High level input connector.
Option 2: Line input connection
Connect the amplier to the car audio with an RCA cable (not supplied)
Left speaker
Right speaker
White / Black
White Grey
Grey / Black
Car audio unit
320Hz
30Hz
SUB
WOOFER
SUBSONIC
ON OFF
REMOTE
LEVEL CONTROL
LINE OUT
Car audio unit
320Hz
30Hz
SUB
WOOFER
SUBSONIC
ON OFF
REMOTE
LEVEL CONTROL
