Spare parts list
GB 71CDR775 10.
10. Spare parts list
Mechanical Parts List 775
Cabinet Parts
3104 129 52531 COMPLETE CDR775
MODULE
0001 3104 127 08720 FRONT ASSY COMPLETE
CDR775
0003 3104 127 08710 KEY UNIT MIDDLE ASSY
CDR775
0009 4822 410 11962 POWER BUTTON BLACK
0014 4822 459 10887 WORDMARK PLATE
0015 4822 454 13339 CDRW LOGO PLATE,
NAME
0051 3104 124 05700 EASY JOG KNOB CDR775
0052 4822 492 51374 SPRING (RING)
0053 3104 124 05620 TRANSPARENT FRAME
BUTTON
0054 3104 124 05620 TRANSPARENT FRAME
BUTTON
0076 3104 144 05730 SUSPENSION
0077 3104 144 05730 SUSPENSION
0078 3104 144 05730 SUSPENSION
0079 3104 144 05730 SUSPENSION
0131 3104 147 13300 CD LOADER VAL 1250
0165 4822 442 01506 COVER
0251 4822 462 42159 FOOT SILVER
0252 4822 462 42159 FOOT SILVER
0253 4822 462 42158 FOOT BLACK
0254 4822 462 42158 FOOT BLACK
0301 4822 321 10249 SBC1201 MAINS CABLE
0309 3104 125 22870 USER MANUAL CDR775/
776/00 WEU
0312 4822 321 62401 AUDIO CABLE
0313 4822 321 62401 AUDIO CABLE
0317 4822 321 61452 DIG OUT CABLE
0318 3139 228 82010 REMOTE CONTROL
RC282921/01
1003 3122 427 21570 PSU CDR-3 SINGLE
RANGE EURO
8001 3104 157 11240 CWAS FLEX 1MM 14 100
32S
8005 3104 157 11230 CWAS FLEX 1MM 22 320
32S
8007 3104 157 11320 CWAS FLEX 1.25MM 7 300
32S
CD Loader VAL1250
0001 3104 147 14100 CHASSIS ASSY LOADER
VAL 1250
0002 4822 361 11131 TRAY MOTOR ASSY
0003 4822 492 11709 MOTOR SPRING
0004 4822 277 11838 SWITCH
0006 4822 532 13097 TULE
0010 4822 528 11295 PULLEY WHEEL
0011 4822 358 10266 BELT, DRIVING
0012 4822 522 10739 RACK GEAR WHEEL
0013 4822 535 10588 PIN, PLASTIC
0014 4822 522 10741 TRAY GEAR WHEEL
0015 4822 535 10588 PIN, PLASTIC
0016 4822 402 11221 RACK
0017 4822 492 11711 RACK SPRING
0020 4822 466 12131 CUSHION RUBBER
0021 4822 466 12131 CUSHION RUBBER
0022 4822 466 12131 CUSHION RUBBER
0023 4822 466 12131 CUSHION RUBBER
0030 9305 022 25001 CDM VAM 1250
0035 3104 144 02030 SUSPENSION
0036 3104 144 02030 SUSPENSION
0037 3104 144 02030 SUSPENSION
0038 3104 144 02030 SUSPENSION
0040 3104 144 05870 SUB-CHASIS
0042 4822 492 11709 MOTOR SPRING
0043 4822 418 10421 TRAY HORIZONTAL
0045 3104 147 13910 CLAMPER ASSY VAL 1250
8001 3104 148 01310 LED ASSY 4P
Display Board Assy 775
Miscellaneous
0003 3104 124 05710 FTD HOLDER
1050 2422 129 16314 ROT.ENCODER + SWITCH
1101 4822 276 13114 SWITCH, PUSH BUTTON
1102 4822 276 13114 SWITCH, PUSH BUTTON
1103 4822 276 13114 SWITCH, PUSH BUTTON
1104 4822 276 13114 SWITCH, PUSH BUTTON
1105 4822 276 13114 SWITCH, PUSH BUTTON
1106 4822 276 13114 SWITCH, PUSH BUTTON
1107 4822 276 13114 SWITCH, PUSH BUTTON
1108 4822 276 13114 SWITCH, PUSH BUTTON
1109 4822 276 13114 SWITCH, PUSH BUTTON
1110 2422 540 98423 RES CER 8MHz CSTS*MHz
03
1111 4822 276 13114 SWITCH, PUSH BUTTON
1112 4822 276 13114 SWITCH, PUSH BUTTON
1113 2722 171 07174 VFD 15-BT-60GNK 106*40
(FTB0)B
1114 4822 276 13114 SWITCH, PUSH BUTTON
1115 4822 276 13114 SWITCH, PUSH BUTTON
1116 4822 276 13114 SWITCH, PUSH BUTTON
1117 4822 276 13114 SWITCH, PUSH BUTTON
1118 4822 276 13114 SWITCH, PUSH BUTTON
1120 4822 276 13114 SWITCH, PUSH BUTTON
1125 4822 276 13114 SWITCH, PUSH BUTTON
1126 4822 276 13114 SWITCH, PUSH BUTTON
1127 4822 276 13114 SWITCH, PUSH BUTTON
1128 4822 276 13114 SWITCH, PUSH BUTTON
1130 4822 276 13441 SWITCH TACT LED
1131 4822 276 13441 SWITCH TACT LED
1301 4822 276 14007 SWI PUSH 2P 0.1A 12V
1401 4822 267 31453 SWITCH, PUSH BUTTON
1500 4822 267 31729 CON BM CINCH H 1P F
1501 4822 265 11406 CON BM CINCH V 2P F
WHRD B
1502 4822 265 30987 BMT 7SR>CBL0,3-1,25
g
2100 4822 126 14585 100nF 10% 50V
2101 4822 126 14585 100nF 10% 50V
2102 5322 122 32654 22nF 10% 63V
2104 5322 122 32658 22pF 5% 50V
2106 5322 122 32658 22pF 5% 50V
2111 4822 126 14585 100nF 10% 50V
2400 5322 122 31647 1nF 10% 63V
2401 5322 122 31647 1nF 10% 63V
2500 4822 124 11947 10
µ
F 20% 16V
2501 4822 126 12105 50V 33nF PM5
2502 4822 126 12105 50V 33nF PM5
2503 4822 122 33575 220pF 5% 63V CASE
2504 4822 122 33575 220pF 5% 63V CASE
f
3100 4822 051 20472 4k7 5% 0.1W
3101 4822 051 20472 4k7 5% 0.1W
3102 4822 051 20472 4k7 5% 0.1W
3103 4822 051 20472 4k7 5% 0.1W
3104 4822 051 20472 4k7 5% 0.1W
3105 4822 051 20472 4k7 5% 0.1W
3106 4822 117 11149 82k 1% 0.1W
3107 4822 051 20472 4k7 5% 0.1W
3108 4822 051 20101 100
Ω
5% 0.1W
3109 4822 051 20561 560
Ω
5% 0.1W
3111 4822 051 20101 100
Ω
5% 0.1W
3112 4822 051 20393 39k 5% 0.1W
3113 4822 117 10833 10k 1% 0.1W
3114 4822 117 10833 10k 1% 0.1W
3115 4822 051 20561 560
Ω
5% 0.1W
3116 4822 051 20561 560
Ω
5% 0.1W
3122 4822 117 11149 82k 1% 0.1W
3124 4822 117 11149 82k 1% 0.1W
3125 4822 051 20332 3k3 5% 0.1W
3500 4822 117 12521 68
Ω
1% 0.1W
3501 4822 117 11448 180
Ω
1% 0.1W
3502 4822 117 11449 2k2 1% 0.1W
3503 4822 117 11448 180
Ω
1% 0.1W
3504 4822 117 11449 2k2 1% 0.1W
4xxx 4822 051 10008 0
Ω
5% 0.25W (1206)
4xxx 4822 051 20008 0
Ω
5% 0.25W (0805)
b
5500 4822 157 70601 100
µ
H (920927085A)
d
6100 4822 130 11411 BZX284-C3V3
6200 4822 212 30842 TSOP1736SB1
6300 4822 130 82978 LTL-16KPE-P
ce
7100 4822 130 60511 BC847B
7104 3104 123 94761 ROM TMP87CH74
7203 4822 130 60511 BC847B
7204 4822 130 60511 BC847B
7500 4822 130 60511 BC847B
7501 4822 130 60511 BC847B
CD Main Board
Miscellaneous
1000 2422 025 11704 CON BM H 16P F 1.00 FFC
0.3 R
1004 2422 543 00896 RES XTL SM 8M4672 30P
CX-5F R
1006 4822 267 51454 CONN. 11P FEMALE
1205 5322 242 73686 CST12,00MTW-TF01
1206
h
4822 252 51173 19398E1(1,000A)
1207
h
4822 252 51173 19398E1(1,000A)
1208 4822 267 60409 CONN 22P FEMALE
1209 4822 265 30987 BMT 7SR>CBL0,3-1,25
1210 2422 025 11704 CON BM H 16P F 1.00 FFC
0.3 R
g
2100 4822 126 14585 100nF 10% 50V
2102 4822 126 14585 100nF 10% 50V
2103 5322 122 31647 1nF 10% 63V
2104 4822 126 14585 100nF 10% 50V
2105 4822 124 81286 47
µ
F 20% 16V
2106 4822 126 14585 100nF 10% 50V
2107 4822 124 81286 47
µ
F 20% 16V
2109 5322 122 32654 22nF 10% 63V
2110 4822 126 14585 100nF 10% 50V
2111 4822 126 14585 100nF 10% 50V
2112 4822 126 14585 100nF 10% 50V
2113 4822 126 14585 100nF 10% 50V
2114 4822 126 14585 100nF 10% 50V
2115 4822 126 14585 100nF 10% 50V
2116 4822 124 41796 22
µ
F 20% 16V
2117 5322 122 32654 22nF 10% 63V
2118 4822 126 14585 100nF 10% 50V
2119 4822 126 14585 100nF 10% 50V
2120 4822 124 41796 22
µ
F 20% 16V
2121 4822 126 14585 100nF 10% 50V
2122 4822 126 12104 12nF 5% 50V
2123 5322 122 31863 63V 330pF PM5
2124 4822 126 14585 100nF 10% 50V
2125 4822 124 81286 47
µ
F 20% 16V
2126 5322 122 34098 10nF 10% 63V
2127 5322 122 31863 63V 330pF PM5
2128 4822 124 80483 47
µ
F 20% 6.3V
2130 4822 126 14305 100nF 10% 16V 0603
2131 4822 126 14585 100nF 10% 50V
2132 4822 124 80483 47
µ
F 20% 6.3V
2133 4822 126 13482 470nF 80/20% 16V
2134 4822 126 14305 100nF 10% 16V 0603
2135 4822 124 41796 22
µ
F 20% 16V
2137 4822 126 14494 22nF 10% 25V 0603
2138 4822 126 14494 22nF 10% 25V 0603
2139 4822 126 14305 100nF 10% 16V 0603
2140 4822 126 14508 180pF 5% 50V 0603
2141 4822 126 14238 0603 50V 2N2 COL R
2142 5322 122 32654 22nF 10% 63V
2143 4822 126 14241 0603 50V 330P COL R
2145 4822 126 13692 47pF 1% 63V
2146 4822 126 14247 0603 50V 1N5 COL R
