Philips CDR775 - Spare parts list (Continued); Power Supply Unit Parts

Spare parts list
GB 73CDR775 10.
7301 4822 130 60511 BC847B
7309 4822 209 17237 UDA1320ATS
7310 4822 130 60511 BC847B
I/O Board
Miscellaneous
1000 2422 025 16289 CON 14P PRINTCON.
1001 4822 267 31448 CINCH 2P
1002 4822 265 11151 CINCH 4P
g
2016 5322 122 32654 22nF 10% 63V
2017 5322 122 32654 22nF 10% 63V
2018 5322 122 32654 22nF 10% 63V
2019 4822 124 40248 10
µ
F 20% 63V
2020 5322 122 32654 22nF 10% 63V
2022 4822 126 12105 50V 33nF PM5
2023 5322 122 32654 22nF 10% 63V
2024 5322 122 32654 22nF 10% 63V
2025 5322 122 33538 150pF 2% 63V
2026 5322 122 32531 100pF 5% 50V
2027 5322 122 32531 100pF 5% 50V
2028 5322 122 32659 33pF 5% 50V
2029 5322 122 32659 33pF 5% 50V
2030 5322 122 32659 33pF 5% 50V
f
3020 4822 117 12521 68
Ω
1% 0.1W
3021 4822 051 20332 3k3 5% 0.1W
3022 4822 117 11152 4
Ω
7 5%
3024 4822 051 20332 3k3 5% 0.1W
3026 4822 051 20332 3k3 5% 0.1W
3027 4822 051 20332 3k3 5% 0.1W
3028
h
4822 117 11152 4
Ω
7 5%
3029 4822 117 11927 75
Ω
1% 0.1W
3032 4822 117 11373 100
Ω
1% RC12H 0805
3033 4822 117 11373 100
Ω
1% RC12H 0805
3034 4822 117 11449 2k2 1% 0.1W
3035 4822 117 11449 2k2 1% 0.1W
3036 4822 117 11373 100
Ω
1% RC12H 0805
3037 4822 117 11373 100
Ω
1% RC12H 0805
3038 4822 117 11449 2k2 1% 0.1W
3039 4822 117 11449 2k2 1% 0.1W
b
5001 4822 157 70601 100
µ
H (920927085A)
5002
h
4822 157 71206 BLM21A601SPT
d
6000 4822 218 11487 GP1F32R
ce
7005 5322 209 11517 PC74HCU04T
7006 4822 130 60511 BC847B
7007 4822 130 60511 BC847B
7008 4822 130 60511 BC847B
7009 4822 130 60511 BC847B
Power Supply Unit 20PS317
Miscellaneous
0006 4822 492 63524 SPRING FIX. TRANSISTOR
0101
h
4822 265 31015 CONNECTOR, MAINS
INLET
1120
h
4822 070 32002 FUSE 218002.(2A)
1121 3122 358 72141 FUSE HOLDER CLICK
1125 4822 252 60151 SURGE PROTECT DSP-
501N-A21F
g
2101 4822 126 13695 82pF 1% 63V
2102 5322 126 10184 820P 5% 50V 3
2103 5322 122 32268 470pF 10% 50V
2104 5322 126 10223 4.7nF 10% 63V
2109 5322 122 31865 1.5nF 10% 63V
2110 4822 124 22652 2.2
µ
F 20% 50V
2111 4822 126 14585 100nF 10% 50V
2113 4822 122 33127 2.2nF 10% 63V
2114 4822 126 14585 100nF 10% 50V
2125 4822 121 51598 2.2nF 5% 400V
2126 4822 121 51598 2.2nF 5% 400V
2127 4822 126 14496 470pF 10% 1KV
2129 4822 124 23057 4.7
µ
F 20% 50V
2131
h
4822 126 14497 2.2nF 20% 250V
2133 4822 124 12062 100
µ
F 20% 25V
2201 4822 126 14585 100nF 10% 50V
2202 5322 122 32654 22nF 10% 63V
2210 4822 124 12282 2200
µ
F 20% YK 10V
2220 4822 124 40849 330
µ
F 20% 16V
2221 4822 126 13751 47nF 10% 63V
2222 4822 124 12283 100
µ
F 20% MS7 6.3V
2230 4822 124 81144 1000
µ
F 16V
2240 4822 124 81144 1000
µ
F 16V
2242 4822 124 41584 100
µ
F 20% 10V
2250 4822 124 40248 10
µ
F 20% 63V
2252 4822 124 11769 220
µ
F 20% 50V
2260 4822 122 31175 1nF 10% 500V
f
3101 4822 116 52304 82k 5% 0.5W
3102 4822 051 20223 22k 5% 0.1W
3103 4822 051 20472 4k7 5% 0.1W
3104 4822 116 83933 15k 1% 0.1W
3105 4822 116 83933 15k 1% 0.1W
3106 4822 051 20102 1k 5% 0.1W
3107 4822 051 20184 180k 5% 0.1W
3108 4822 117 10965 18k 1% 0.1W
3109 4822 117 13577 330
Ω
1% RC12H 0805
1.25W
3110 4822 117 10833 10k 1% 0.1W
3111 4822 051 20229 22
Ω
5% 0.1W
3112 4822 051 20101 100
Ω
5% 0.1W
3113 4822 051 20159 15
Ω
5% 0.1W
3115 4822 116 52232 910
Ω
5% 0.5W
3116 4822 117 11448 180
Ω
1% 0.1W
3120
h
2122 550 00147 VDR DC 1mA/423V
3123 4822 050 21803 18k 1% 0.6W
3124 4822 116 83872 220
Ω
5% 0.5W
3125 4822 050 21002 1k 1% 0.6W
3126 4822 116 80176 1
Ω
5% 0.5W
3127 4822 116 80676 1
Ω
5 5% 0.5W
3128 4822 116 80676 1
Ω
5 5% 0.5W
3129 4822 050 21003 10k 1% 0.6W
3134 4822 050 21803 18k 1% 0.6W
3201 4822 116 52176 10
Ω
5% 0.5W
3202 4822 050 13302 3k3 1% 0.4W
3203 4822 116 52175 100
Ω
5% 0.5W
3204 4822 051 20182 1k8 5% 0.1W
3205 4822 117 10353 150
Ω
1% 0.1W
3206 4822 117 11143 3k 1% 0.1W
3221 4822 051 20471 470
Ω
5% 0.1W
3222 4822 051 20241 240
Ω
5%
3230 4822 050 21002 1k 1% 0.6W
3231 4822 117 10833 10k 1% 0.1W
3232 4822 051 20113 11k 5% 0.1W
3233 4822 117 10833 10k 1% 0.1W
3234 4822 117 10833 10k 1% 0.1W
b
5120
h
4822 157 11846 FILTER, MAINS
5125 4822 157 11411 100mH z
5132 4822 157 51462 10
µ
H 10% 4X9.8MM
LAL04T100K
5210 4822 157 11722 6.8
µ
H 20% 7.7X9.5
5220 4822 157 51462 10
µ
H 10% 4X9.8MM
LAL04T100K
5225 4822 157 53139 4.7
µ
H
5226 4822 157 53139 4.7
µ
H
5230 4822 157 50963 2.2
µ
H
5240 4822 157 51462 10
µ
H 10% 4X9.8MM
LAL04T100K
5250 4822 157 51462 10
µ
H 10% 4X9.8MM
LAL04T100K
5255 4822 157 51195 1
µ
H 20% 4X9.8MM AXIAL
d
6102 4822 130 83707 SINB80
6106 4822 130 42606 BYD33J
6107 4822 130 42606 BYD33J
6114 4822 130 42488 BYD33D
6129 5322 130 80122 BZX84-C24
6132 4822 130 42488 BYD33D
6220 4822 130 42488 BYD33D
6231 4822 130 31603 1N4006
6232 4822 130 11584 BYW98-200-C1
6240 4822 130 42488 BYD33D
6250 4822 130 42606 BYD33J
ce
7110 4822 209 15684 MC44603AP
7125 4822 130 63787 STP4NA60FI
7200
h
4822 130 91451 CQY80NG
7201 4822 209 16944 KA431AZ
7221 4822 209 80591 LM317T
7249 4822 209 82112 MC7908CT
7251 5322 130 60159 BC846B
7252 4822 130 60373 BC856B
