13
Attach the front panel
1 Attach the trim plate.
2 Insert the right side of the panel in the
chassis until it is correctly engaged.
3 Press the left side of the panel until the
mechanism locks it into place.
Place the DAB antenna
Warning
Make sure the antenna cable does not •
interfere with the safe operation of driving
wheel, air bags and seatbelts or other
equipment.
Before entering low overhangs, car washes, or
•
other places with obstacles which may catch
on or touch the antenna, remove the antenna
to avoid potential damage.
Damage caused by not following the
•
installation instructions is not covered by
warranty.
6 Place the supplied rubber cushion over
the end of the mounting bolt.
7 Slide the unit into the dashboard until you
hear a click sound.
8 Reconnect the negative terminal of the
car battery.
5mm
English
EN
