26
Compatible USB devices:
USB flash memory: USB 1.1 host with •
interface reading all speed support (1.1, 2.0)
USB flash players: USB 1.1 host with •
interface reading all speed support (1.1, 2.0)
Supported formats:
USB or memory file format: FAT16, FAT32•
MP3 bit rate (data rate): 32-320 Kbps and •
variable bit rate
WMA V4, V7, V8, V9 (L1, L2)•
ISO9660, Joliet•
Maximum title number: 512 (depending •
on file name length)
Maximum album number: 255•
Supported sampling frequencies: 2 kHz, •
44.1 kHz, 48 kHz
Supported Bit-rates: 2~256 (kbps), •
variable bit rates
Directory nesting up to a maximum of •
8 levels
Number of albums/ folders: CD •
maximum 99, USB maximum 199
Number of tracks/titles: maximum 999•
ID3 tag v2.0 to v2.4•
File name in Unicode UTF8 (maximum •
length 64 bytes)
Unsupported formats:
Empty albums: an empty album is an •
album that does not contain MP3/WMA
files, and is not be shown in the display.
Unsupported file formats are skipped. For •
example, Word documents (.doc) or MP3
files with extension .dlf are ignored and
not played.
AAC, WAV, PCM audio files•
DRM protected WMA files (.wav, .m4a, •
.m4p, .mp4, .aac)
WMA files in Lossless format•
9 Product
information
Note
Product information is subject to change •
without prior notice.
Power supply 12 V DC (11 V -
16 V), negative
ground
Fuse 15 A
Suitable speaker
impedance
4 - 8
Maximum power output 45 W x 4 channels
Continuous power
output
22 W x 4 RMS
(4
10% T.H.D.)
Pre-Amp output voltage 2.5 V
Aux-in level
500 mV
Dimensions (W x H x D) 188 x 58 x 201 mm
Weight 1.47 kg
Radio
Frequency range -
FM
87.5 - 108.0 MHz
(100kHz per step in auto
search and 50kHz per
step in manual search)
Frequency range -
AM (MW)
522 - 1620 KHz (9 kHz)
530 - 1710 kHz (10 kHz)
Usable sensitivity -
FM
8 μV
Usable sensitivity -
AM (MW) (S/N =
20 dB)
30 μV
DAB Tuner
Frequency range 174 - 240 MHz
Sensitivity -100dBm(Band III)
Selectivity 40dB
EN
