6 EN
Side right
AUDIO IN
Audio input from, for example, an MP3 player
(3.5mm jack).
Rear left
a SUBWOOFER
Connect to the supplied subwoofer.
b AUDIO IN-AUX
Connect to an analog audio output on the
TV or an analog device.
c DIGITAL IN-COAXIAL
Connect to a coaxial audio output on the
TV or a digital device.
d DIGITAL IN-OPTICAL
Connect to an optical audio output on the
TV or a digital device.
1
2 3
4
Rear right
AC MAINS~
Connect to the power supply.
AC MAINS~
