Philips DST7510/80 - Service Lists; Part List

Published by Philips Domestic Appliances Page 19 of 26 For internal use only
Document No. : CSW-07-081-22188
Reassembly Instruction (continue)
5.Service Lists
5.1 Part list
POS.
Description
DST7510/80
DST7511/80
DST7011/20
DST7011/26
889015180040
889015680040
889006820040
889006826600
889015180270
889015680270
889006820270
AE,KE,KW,
TURKEY
TURKEY
TURKEY
NG,SA,ZM
EU9
EU9
EU9
1
ASO
423902292101
423902292101
-
-
2
BACKPLATE
423902275261
423902292761
423902293871
423902293871
3
CALC COLLECTOR ASSY
423902273941
423902273941
423902273941
423902273941
4
COVER & SOLEPLATE ASSY
423902292111
423902292771
423902275521
423902275521
5
INLAY ASSY
423902275311
423902274161
423902294051
423902294051
6
MAINSCORD
423902292121
423902292121
423902273981
423902294991
MAINSCORD #
-
-
-
642001006360
7
WATER TANK ASSY
642001003113
642001003120
642001003121
642001003121
8
SPRAY KNOB
423902292141
423902292791
423902294141
423902294141
9
LAMP ASSY
423902292151
423902292151
423902292151
423902292151
10
BALL SWIVEL
423902292161
423902283651
423902282991
423902282991
11
THERMOSTAT DIAL PRTED
423902292171
423902292801
423902294181
423902294181
12
BULLET
423902283261
423902283261
423902283261
423902283261
13
BULLET SPRING
423902283271
423902283271
423902283271
423902283271
14
DECO PLATE
423902292181
423902292811
423902293981
423902293981
15
TANK TOP SEAL
423902292191
423902288481
423902282501
423902282501
27. Tighten BACKPLATE 1 to WATER TANK
ASSY 7 with 2x Screw A1
28. Assemble CALC COLLECTOR DOOR ASSY
3 and slide the switch to 'lock' position
V2
V2
V5
V7
