11
2. Setting up the monitor
3. Remove the hinge cover from
monitor body by using your fingers.
4. Use a screwdriver to remove the
screws on the arm, and then detach
the arm/stand from the monitor.
Note
This monitor accepts a 100mm x 100mm
VESA-Compliant mounting interface.
VESA Mounting Screw M4. Always
contact manufacturer for wall-mount
installation.
100mm
100mm
241E1C
1. Place the display face down on a
smooth surface. Pay attention not to
scratch or damage the screen.
2. Use screwdriver to loosen the screw
located at the bottom of the base,
and remove the base from the
stand.
2
1
3. Remove the hinge cover from
monitor body by using your fingers.
To Next Page
