Sensor view shield
The sensor comes with an occupancy view shield that can
be used to block the movement detection by the sensor in
a certain area. The shield comes inverted. (See Figure 2.)
This view shield can be pulled out, flipped and inserted
back in the sensor and then rotated so the correct area is
shielded off from the detection area. If such shield is not
needed in the application, it can be easily pulled out from
the sensor or left as in the original position.
To prevent false triggers, the EasyAir SNS210 MC must
be mounted more than 2 m away from air vents in all
directions, see figures below:
> 2m
> 2m
Luminaire
> 2m
> 2m
• Occupancy view shield
Figure 2. Sensor view shield.
