19
English
EN
7 Wall mount
your SoundBar
Before you mount your SoundBar on the wall,
read all safety precautions.
Wall mount
Note
• You must detach the portable speakers from the main
unit before wall mounting or un-mounting.
• Improper wall mounting may result in accident, injury or
damage. If you have any query, contact Consumer Care
in your country.
• Secure the wall mount to a wall that can support the
combined weight of the product and the wall mount.
• Before wall mount, you need not remove the four
rubber feet at the bottom of the soundbar, otherwise
Screw length/diameter
Depend on the type of wall mounting this wall
mount bracket, make sure that you use screws
of a suitable length and diameter.
See the illustration on the separate wall mount
sheet on how to wall mount the SoundBar.
dowels and screws.
> 25mm
3 - 3.5mm
8 Product
specifications
Note
•
notice.
• FTC total output power: 94 W
• Front Left + Right:
• Surround Left + Right:
• Subwoofer:
• Total output power:
• Frequency response: 20 Hz-20 kHz / ±3 dB
• Signal-to-noise ratio:
• Input sensitivity:
• AUX: 750 mV
• AUDIO IN: 400 mV
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
Bluetooth
•
• Bluetooth version: 2.1 + EDR
Main unit
• Power supply: 110-240 V~, 50-60 Hz
• Power consumption: 50 W
•
B5_37_UM_V1.0.indb 19 7/31/2015 5:22:55 PM
