7 EN
Connectors
This section includes an overview of the
connectors available on the main unit.
a DC IN
Connect to the power supply.
b AUDIO IN
Connect to an audio output (3.5mm
jack) on a device.
c OPTICAL IN
Connect to an optical audio output on
the TV or a digital device.
d USB (For service)
Connect to a USB ash drive to upgrade
software of this product.
e HDMI OUT (eARC/ARC)
Connect to the HDMI (eARC/ARC) input
on the TV.
f HDMI IN 1 / HDMI IN 2
Connect to the HDMI output on a digital
device.
