7 Patient Alarms and INOPs
138
cl F&M Chk Electr. Monitor: INOP tone
without tone, if no CL F&M
Pod parameter shows -?-
CL F&M Pod: cyan LED
• Not all electrodes have sufficient skin contact:
Prepare the skin at the application site further with
the abrasive pad.
• One or more leads between the measurement Pod
and the electrode(s) is broken: Replace the electrode
patch.
• Contact problem between the CL F&M Pod and the
electrode patch: Reconnect the CL F&M Pod.
This INOP can only occur in monitoring mode after the
initial electrode impedance check has occurred.
cl F&M ChkSettings Monitor: INOP tone
CL F&M Pod: cyan LED
The CL F&M Pod settings are incompatible or corrupted.
Check the settings. Contact your service personnel.
cl F&M Disconnect Monitor: INOP tone
CL F&M Pod: cyan LED
The CL F&M Pod has lost the connection to the monitor.
Call the patient back to the monitor. If the CL F&M Pod
has still no connection, remove it from the monitor, and
reassign it. If it still does not have a connection, contact
your service personnel.
cl F&M License Req Monitor: INOP tone
CL F&M Pod: cyan LED
There is no valid license registered. Contact your service
personnel.
cl F&M Malfunction Monitor: INOP tone
CL F&M Pod: cyan LED
The CL F&M Pod malfunctions. Contact your service
personnel.
cl F&M Patch Disc Monitor: INOP tone
CL F&M Pod: cyan LED
The CL F&M Pod has been disconnected from the
electrode patch during monitoring mode. Reconnect the
CL F&M Pod.
cl F&M Patch Malf Monitor: INOP tone
CL F&M Pod: cyan LED and
INOP tone
The connected electrode patch cannot be identified.
Either the electrode patch is malfunctioning, or the
connection between the CL F&M Pod and the patch is
defective.
cl F&M Remove Monitor: INOP tone
CL F&M Pod: cyan LED and
INOP tone
The battery temperature is too high 60°C (140°F).
Remove the CL F&M Pod immediately from the patient.
Contact your service personnel.
INOP Message Indication What to do
