NOTE: Be care-full, when you press the microphone button, you can transmit 5 watts.
As a final test, with channel 20 setup on the FM92E connect your signal generator to 53.000 MHz. You should
hear a signal through the FM92E with approximately 100 mVolt of signal.
NOTE: If the VCO will not tune properly or the transmitter side will not come within voltage range, then check
that pin 19 of the VCO module is 0 Volts on receive and 10 Volts on transmit.
VCO Tune Check References:
Ch # Rx Freq Injection Frequency VCO Voltage
21.4MHz 10.7MHz Rx Tx
3 70.000MHz 80.7MHZ 5.3v 4.7V Not Converted
10 77.000MHz 98.4MHz 9.6V 12.0V Not Converted
20 53.000MHz 74.4MHz
20 53.000MHz 63.7MHz
Philips FM92E Conversion to 6 Meters: Version 3.9 Page 36
