3: Files Associated with this Project:
6m_con.doc = Documentation to convert Philips FM92E to 6 Meters. Note: Approximately 10Mb.
6m_con.pdf = Documentation to convert Philips FM92E to 6 Meters. Note: Approximately 3.5Mb.
6m_fre.rtf = Frequency list of channels of EPROM's below.
EPROM’s for 6 Meters transmitter & receiver after modification.
6m1loc.bin = EPROM for Philips FM92E with Local Head.
Hardware Code: = 9502 9221
0000 25.0KHz channel, 25W & 10.7 MHz IF.
Software Code = 110400200000000 Check Sum = C2FF
6m2rem.bin = EPROM for Philips FM92E with Remote Head.
Hardware Code: = 9502 9222 0000 25.0KHz channel, 25W & 10.7 MHz IF.
Software Code = 110400200000000 Check Sum = 09FF
6m3loc.bin = EPROM for Philips FM92E with Local Head
Hardware Code: = 9502 9223 0000 25.0 KHz channel, 25W & 21.4 MHz IF.
Software Code = 110400200000000 Check Sum = B8FF
6m4rem.bin = EPROM for Philips FM91E changed to FM92E with Remote Head
Hardware Code: = 9502 9224 0000 25.0 KHz channel, 25W & 21.4 MHz IF.
Software Code = 110400200000000 Check Sum = FFFF
6m5loc.bin = EPROM for Philips FM92E with Local Head.
Hardware Code: = 9502 9225 0000 12.5 KHz channel, 25W & 10.7 MHz IF.
Software Code = 110400200000000 Check Sum = AAFF
6m6rem.bin = EPROM for Philips FM92E with Remote Head.
Hardware Code: = 9502 9226 0000 12.5 KHz channel, 25W & 10.7 MHz IF.
Software Code = 110400200000000 Check Sum =
6m7loc.bin = EPROM for Philips FM92E with Local Head.
Hardware Code: = 9502 9227 0000 12.5 KHz channel, 25W & 21.4 MHz IF.
Software Code = 110400200000000 Check Sum = 2FFF
6m8rem.bin = EPROM for Philips FM92E with Remote Head.
Hardware Code: = 9502 9228 0000 12.5 KHz channel, 25W & 21.4 MHz IF.
Software Code = 110400200000000 Check Sum =
EPROMs for testing FM92E 66-88 MHz transmitter & receiver before modification.
6mtest1l.bin = EPROM for Philips FM92E with Local Head.
Hardware Code: = 9502 9221 0000 25.0KHz channel, 25W & 10.7 MHz IF.
Software Code = 110400000000000 Check Sum = AFFF
6mtest2r.bin = EPROM for Philips FM92E with Remote Head.
Hardware Code: = 9502 9222 0000 25.0KHz channel, 25W & 10.7 MHz IF.
Software Code = 110400000000000 Check Sum = F6FF
6mtest3l.bin = EPROM for Philips FM92E with Local Head.
Hardware Code: = 9502 9223 0000 25.0KHz channel, 25W & 21.4 MHz IF.
Software Code = 110400000000000 Check Sum = ADFF
6mtest4r.bin = EPROM for Philips FM91E converted to FM92E with Remote Head.
Hardware Code: = 9502 9224 0000 25.0KHz channel, 25W & 21.4 MHz IF.
Software Code = 110400000000000 Check Sum = F4FF
NOTE: You must determine what IF your FM92E is using. This will determine what EPROM to use. The IF frequency is
normally located on the side panel of the VCO under RF/BW. It will be either 10.7 or 21.4 MHz.
