Alignments
EN 101FTL2.4E AA 8.
Table 8-7 Option overview
Byte Bit (dec. value) Subject Options Settings (in decimal values) Remarks
1 0 (1) Video Repro Feature Box Type 3= Eagle 1B, 4= Eagle 1C, 5= 1050i/1250i
1 (2)
2 (4)
3 (8) Personal Ambi Light Demo 0= Off, 8= On
4 (16) Video Repro Auto Scavem 0= No, 16= Yes Only selectable for CRT sets.
5 (32) Improv. Noise Reduction 0= No, 32= Yes Fixed to "Yes" in case Columbus is present
6 (64) Light Sensor 0= No, 64= Yes
7 (128) n.a. n.a.
8 (256) Video Repro Digital Option 0 (No)= Dig. Natural Motion (for PP1) or PixelPlus
(for PP2), 256 (Yes)= PixelPlus (for PP1) or
PixelPlus2 (for PP2)
This depends on the "Pixel Plus Version" option (see also Byte 1
- bit 14), and gives the info that is visible in the user menu.
9 (512) n.a.
10 (1024) Source Selection 1152i 0= Off, 1024= On
11 (2048) Video Repro n.a.
12 (4096) Signalling Bits 0= No, 4096= Yes Fixed to: "Yes" in EU and AP-P, "No" for other versions.
13 (8192) 3D Comb Filter 0= No (2D Comb), 8192= Yes (3D Comb)
14 (16384) PP (Pixel Plus) Version 0= “1”, 16384= “2” Only selectable when "Feature Box" option is "Eagle 1C". See
also Byte 1- bit 8 "Digital Option".
15 (32768) 720p 0= No, 32768= Yes
2 0 (1) Audio Repro n.a.
1 (2) Dolby Pro Logic 0= No, 2= Yes
2 (4) Virtual Rear Speakers 0= No, 4= Yes Fixed to: "Yes" for sets with Dolby Pro Logic.
3 (8) Cordless Rear Speakers 0= No, 8= Yes Fixed to: "No" for all versions, except for EU.
4 (16) Dolby Digital 0= No, 16= Yes When Dolby Digital is "Yes", the AVL (Byte 8 - bit 6) option must
be "No".
5 (32) Virtual Dolby 0= No, 32= Yes Fixed to: "No" in case the "Dolby Pro Logic" option (Byte 2 - Bit 1)
unequals "none".
6 (64) Sub woofer 0= No Sub woofer present, 64= Sub woofer present.
7 (128)
8 (256) Chassis/Region Chassis 0= EM6, 256= EM5, 512 = EM3 FTx2.x= EM6
9 (512)
10 (1024)
11 (2048)
12 (4096) Teletext n.a.
13 (8192) Flash RAM 0= No, 8192= Yes NexTView type 2C3 and 2 need a Flash RAM.
14 (16384) NexTView type 0= None, 16384= Textguide only,
32768= NexTView 2C3, 49152= NexTView 2
Only available for EU.
15 (32768)
3 0 (1) n.a. n.a.
1 (2) n.a. n.a.
2 (4) n.a. n.a.
3 (8) n.a. n.a.
4 (16) Dual Screen PIP/Dual Screen 0= No, 16= Yes
5 (32) n.a.
6 (64) TXT/EPG Dual Screen 0= No, 64= Yes. Fixed to: "Off" for AP-N, US, and LA versions.
7 (128) n.a.
8 (256) Display CRT type (Aspect Ratio) 0= 4:3, 256= 16:9
9 (512) Picture Rotation 0= No, 512= Yes Only selectable for CRT sets.
10 (1024) Monitor 0= No, 1024= Yes Reserved for Flat TV monitor.
11 (2048) Miscellaneous Integrated Radio 0= No, 2048= Yes
12 (4096) Stand Alone 0= No, 4096= Yes Reserved for Flat TV monitor.
13 (8192) Integrated DVD 0= No, 8192= Yes
14 (16384) Home Cinema 0= No, 16384= Yes Fixed to: "No" in all versions except for EU.
15 (32768) Integrated RC 0= No, 32768= Yes Fixed to: "No" in all versions except for EU.
4 0 (1) Dual Screen DS/PIP (Aux) Tuner 0= Aux Tuner not present,
1= Aux Tuner present
Only selectable in the EU version, provided the "PIP/Dual
Screen" option is "Yes".
1 (2) DS/PIP (Aux) Tuner Type 0= UV1316, 2= TEDE9
2 (4) Miscellaneous 38.0 (or China) IF 0= No, 4= Yes Fixed to: "No" in all versions except for AP-P.
3 (8) Tuner Type 0= UV1316, 8= TEDE9
4 (16) Teletext n.a.
5 (32) n.a.
6 (64) n.a.
7 (128) n.a.
8 (256) Miscellaneous Integrated Dig. Module 0= No, 256= Yes
9 (512) Integrated HDD 0= No, 512= Yes
10 (1024) n.a.
11 (2048) n.a.
12 (4096) Anti Aging 0= No, 4096= Yes Fixed to: "Yes" for FTV.
13 (8192) Personal DVD Door Lock 0= No, 8192= Yes
14 (16384) n.a.
15 (32768) n.a.
