Philips FTL2.4E - 4 Mechanical Instructions

Mechanical Instructions
EN 7FTL2.4E AA 4.
4. Mechanical Instructions
Index of this chapter:
4.1 Cable Dressing
4.2 Service Position
4.3 Assy/PWB Removal
4.4 Display (Dis)Assembly
4.5 Set Re-assembly
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
• Follow the disassemble instructions in described order.
4.1 Cable Dressing
4.1.1 Chassis
Figure 4-1 Chassis cable dressing
F_15490_010.eps
230605
