Technical Specifications, Connections, and Chassis Overview
EN 4 FTL2.4E AA1.
1.3 Chassis Overview
Figure 1-5 PWB locations
E_14620_167.eps
310105
SA
AL
STANDBY SUPPLY/
AUDIO PANEL
E
SIDE CONTROL PANEL
B
SMALL SIGNAL
BOARD
J
LED PANEL
D
SIDE I/O PANEL
H
SCART3 PANEL
A
MAIN SUPPLY
PANEL
AMBI LIGHT PANEL
AL
AMBI LIGHT PANEL
