Philips FW C330 - Page 28

ELECTRICAL PARTSLIST - MAINS BOARD
- MISCELLANEOUS - - COILS & FILTERS -
1201 4822 071 52001 FUSE 19372(200MA) /22/34 5203 4822 157 53473 1000UH 10% 4X9,8 /22/34
1204 2422 132 07519 RELAY 1P 12V 16A /22/34 5204 4822 157 11228 100UH LAN02TB101J 5%
1205 9965 000 07788 FUSE RAD T2A IEC UL250V /21M 5206 4822 157 11832 400UH 3A /22/34
1210 2422 129 16478 VOLTSEL 2P 5A /21M
1212 9965 000 07786 FUSE RAD T4.0A IEC UL250V
5202 2422 549 45157 TRAFO STANDBY /22/34 - DIODES -
5206 4822 157 11832 400UH 3A
6201 4822 130 31878 1N4003G /22/34
6202 4822 130 31878 1N4003G /22/34
- CAPACITORS - 6203 4822 130 30621 1N4148 /22/34
6204 4822 130 30621 1N4148 /22/34
2201 5322 121 42386 100NF 5% 63V /22/34 6205 4822 130 30621 1N4148 /22/34
2202 4822 121 43526 47NF 5% 250V /22/34
2203 4822 126 14559 47NF -80/+20% 50V /22/34 6206 4822 130 31878 1N4003G /22/34
2204 5322 121 42386 100NF 5% 63V /22/34 6207 4822 130 30621 1N4148 /22/34
2205 4822 122 30043 10NF 80% 63V /22/34 6208 4822 130 30621 1N4148 /22/34
6209 4822 130 30621 1N4148 /22/34
2206 4822 121 41856 22NF 5% 250V /22/34 6210 4822 130 30621 1N4148 /22/34
2207 4822 124 40255 100UF 20% 63V /22/34
2208 4822 121 10512 275V 220N 20% /22/34 6211 4822 130 31878 1N4003G /22/34
2209 4822 122 30043 10NF 80% 63V /22/34 6212 4822 130 30621 1N4148 /22/34
2210 2020 561 90365 CER2 Y5V 50V 100N /22/34 6213 4822 130 34173 BZX79-C5V6 /22/34
6214 4822 130 31878 1N4003G /22/34
2211 4822 124 41584 100UF 20% 10V /22/34 6215 4822 130 30621 1N4148 /22/34
2212 4822 124 40207 100UF 20% 25V /22/34
2214 5322 122 32261 4,7NF 10% X7R 100V /22/34 6216 4822 130 34145 BZX79-B39 /22/34
2215 2020 554 90168 CERSAF 250V 330P 10% /22/34 6217 4822 130 30621 1N4148 /22/34
6218 4822 130 30621 1N4148 /22/34
6219 4822 130 34173 BZX79-C5V6 /22/34
- RESISTORS -
3202 4822 050 21003 10K00 1% 0,6W /22/34 - IC & TRANSISTORS -
3203 4822 050 24705 4M70 1% 0,6W /22/34
3204 4822 116 52219 330E 5% 0,5W /22/34 7201 4822 130 44568 BC557B /22/34
3205 4822 116 52228 680E 5% 0,5W /22/34 7202 4822 130 40959 BC547B /22/34
3206 4822 116 52234 100K 5% 0,5W /22/34 7203 4822 130 40981 BC337-25 /22/34
7204 4822 130 40855 BC337 /22/34
3207 4822 116 83866 1M 5% 0,5W /22/34 7205 4822 130 44568 BC557B /22/34
3208 4822 116 83883 470R 5% 0,5W /22/34
3212 4822 050 11002 1K00 1% 0,4W /22/34 7206 4822 130 40959 BC547B /22/34
3214 4822 116 52256 2K2 5% 0,5W /22/34
3215 4822 116 52234 100K 5% 0,5W /22/34
3216 4822 116 83884 47K 5% 0,5W /22/34
3218 4822 116 52283 4K7 5% 0,5W /22/34
3220 4822 116 52175 100E 5% 0,5W /22/34
3221 4822 116 52175 100E 5% 0,5W /22/34
3222 4822 050 23303 33K00 1% 0,6W /22/34
3224 4822 053 21225 2M20 5% 0,5W /22/34
3230 4822 050 23303 33K00 1% 0,6W /22/34
- COILS & FILTERS -
5201 4822 157 53473
1000UH 

10% 

4X9,8 
 
/22/34
!
!
!
!
!
!
!
!
Note : Only the parts mentioned in this list are normal
service spare parts.
/22/34
