ELECTRICAL PARTSLIST - COMBI BOARD
- MISCELLANEOUS - - CAPACITORS -
1102 4822 267 10283 SOCKET COAXIAL 75R 2147 4822 126 13883 220PF 5% 50V /21M/30
1103 4822 265 31184 JST CONNECTOR 2P 2147 4822 122 33575 220PF 5% NP0 63V /22/34
1110 2422 542 90071 FM FRONTEND FE450-G01 /22 2148 4822 126 14238 X7R 50V 2N2 COL /21M/30/34
1214 4822 071 55002 FUSE 19372(5A) /34 2148 4822 122 33575 220PF 5% NP0 63V /22
1215 4822 071 55002 FUSE RAD T5.0A IEC 250V 2149 2222 867 15339 NP0 50V 33P +/-5% /22/34
1216 9965 000 07788 FUSE RAD T2A IEC UL250V 2150 4822 126 14585 100NF 10% X7R 50V
1217 4822 071 53151 FUSE 19372(315MA) 2152 4822 126 14549 33N 16V X7R /21M/30
1300 4822 267 31176 LOUDSPEAKER SOCKET 4P 2152 4822 126 14249 560PF 10% X7R 50V /34
1501 4822 267 10953 FLEX SOCKET 7P VERT. 2153 4822 122 33752 15PF 5% NP0 50V /21M/30
1503 4822 267 10733 CON 4P F 1.25 FFC 0.3 /21M/30 2153 4822 126 11663 12PF /34
1504 4822 265 20553 CINCH SOCKET AUX-IN 2155 2020 800 00191 CTRM 100V 3P-11P /21M/30/34
1507 4822 265 10981 FLEX SOCKET 15P VERT. 2159 2222 867 15339 NP0 50V 33P +/-5%
1508 2422 025 17411 CON 30P F1.25 FFC /21M/30/34 2162 4822 124 81151 22µF 50V /22
1508 2422 025 17412 CON 32P F1.25 FFC /22 2164 3198 017 44740 Y5V 10V 470N COL
2165 2238 586 59812 Y5V 50V 100N +80/-20%
2166 5322 126 11578 1NF 10% X7R 50V /21M/30
- CAPACITORS - 2166 5322 122 31647 1NF 10% X7R 63V /22/34
2167 4822 126 11663 12PF
2101 4822 126 11785 NP0 50V 47P +/-5% /21M/30/34 2169 4822 126 14238 X7R 50V 2N2 COL /22/34
2102 3198 017 41050 Y5V 10V 1U COL R 2180 5322 126 11583 10NF 10% X7R 50V /22
2103 5322 126 11578 1NF 10% X7R 50V /21M/30/34
2104 2020 552 94427 NP0 50V 100P +/-5% R /21M/30/3
4
2191 4822 124 41584 100µF 20% 10V /22
2106 2020 800 00191 CTRM 100V 3P-11P N450 2201 4822 124 40248 10µF 20% 63V
2207 5322 121 42386 100NF 5% 63V
2107 4822 121 51319 1µF 10% 63V 2208 2238 586 59812 Y5V 50V 100N +80/-20%
2120 4822 126 14507 18PF 5% 50V NP0 2209 5322 126 11578 1NF 10% X7R 50V
2124 4822 126 14494 22NF 10% X7R 25V /21M/30
2124 5322 126 11583 10NF 10% X7R 50V /22 2211 4822 124 81039 3300µF 20% 25V
2125 2238 861 18561 NP0 50V 560P PM1 R 2213 5322 121 42386 100NF 5% 63V
2214 5322 121 42386 100NF 5% 63V
2126 4822 126 14241 NP0 50V 330P COL /21M/30/34 2216 4822 124 80415 4700µF 20% 50V
2127 4822 126 13879 220NF +80/-20% 16V 2218 4822 124 80875 220µF 20% 25V
2128 4822 124 40248 10µF 20% 63V
2129 4822 124 41584 100µF 20% 10V 2220 4822 124 80875 220µF 20% 25V
2130 4822 126 14494 22NF 10% X7R 25V 2221 5322 121 42386 100NF 5% 63V
2222 2020 012 93547 ELCAP 63V S 100U +/-20%
2131 3198 017 44740 Y5V 10V 470N COL 2224 4822 124 21913 1µF 20% 63V
2132 3198 017 44740 Y5V 10V 470N COL 2225 4822 124 21913 1µF 20% 63V
2133 4822 124 21913 1µF 20% 63V
2134 3198 017 31530 X7R 50V 15N COL R 2226 4822 121 43526 47NF 5% 250V
2135 3198 017 31530 X7R 50V 15N COL R 2232 4822 126 14494 22NF 10% X7R 25V
2233 4822 124 41751 47µF 20% 50V
2136 4822 126 13879 220NF +80/-20% 16V 2361 3198 016 36810 NP0 25V 680P COL R
2137 4822 126 13879 220NF +80/-20% 16V 2362 3198 016 36810 NP0 25V 680P COL R
2138 4822 124 22652 2,2µF 20% 50V
2139 4822 122 33752 15PF 5% NP0 50V 2365 4822 121 43526 47NF 5% 250V
2140 4822 126 14226 82PF 5% NP0 50V 2366 4822 121 43526 47NF 5% 250V
2367 4822 121 42408 220NF 5% 63V
2141 2238 586 59812 Y5V50V 100N +80/-20% 2368 4822 121 42408 220NF 5% 63V
2143 4822 126 13879 220NF +80/-20% 16V 2369 4822 121 42408 220NF 5% 63V
2144 4822 124 21913 1µF 20% 63V
2145 4822 126 13883 220PF 5% 50V 2370 4822 121 42408 220NF 5% 63V
2146 4822 126 13883 220PF 5% 50V /21M/30 2371 4822 124 40769 4,7µF 20% 100V
2372 4822 124 40769 4,7µF 20% 100V
2146 4822 122 33575 220PF 5% NP0 63V /22/34 2373 4822 126 11785
NP0 50V 47P +/-5%
!
!
!
!

ELECTRICAL PARTSLIST - COMBI BOARD
- CAPACITORS - - CAPACITORS -
2377 4822 124 81151 22UF 50V 2570 4822 124 40433 47UF 20% 25V
2378 4822 126 13883 220PF 5% 50V 2601 4822 124 40433 47UF 20% 25V
2501 4822 124 22466 1UF 20% 50V 2602 2238 586 59812 Y5V 50V 100N +80/-20%
2502 4822 124 22466 1UF 20% 50V 2603 4822 122 33752 15PF 5% NP0 50V
2503 4822 124 22466 1UF 20% 50V 2604 2020 552 94427 NP0 50V 100P +/-5% R
2504 4822 124 22466 1UF 20% 50V 2605 4822 126 13881 470PF 5% 50V
2505 3198 016 31020 NP0 25V 1N 2606 4822 126 13881 470PF 5% 50V
2506 3198 016 31020 NP0 25V 1N 2607 4822 126 13883 220PF 5% 50V
2507 4822 124 22466 1UF 20% 50V 2608 4822 126 13883 220PF 5% 50V
2508 4822 124 22466 1UF 20% 50V 2609 4822 124 81151 22UF 50V
2509 4822 124 22466 1UF 20% 50V 2610 4822 124 81151 22UF 50V
2510 4822 124 22466 1UF 20% 50V 2611 2020 552 94427 NP0 50V 100P +/-5% R
2511 2020 552 94427 NP0 50V 100P +/-5% R 2612 2020 552 94427 NP0 50V 100P +/-5% R
2512 2020 552 94427 NP0 50V 100P +/-5% R 2613 4822 124 41584 100UF 20% 10V
2513 4822 124 22466 1UF 20% 50V 2614 4822 126 14494 22NF 10% X7R 25V
2514 4822 124 22466 1UF 20% 50V 2615 4822 124 41751 47UF 20% 50V
2515 2020 552 94427 NP0 50V 100P +/-5% R 2616 4822 126 14494 22NF 10% X7R 25V
2516 2020 552 94427 NP0 50V 100P +/-5% R 2617 4822 124 40248 10UF 20% 63V
2517 2020 552 94427 NP0 50V 100P +/-5% R 2618 2020 552 94427 NP0 50V 100P +/-5% R
2518 2020 552 94427 NP0 50V 100P +/-5% R 2662 4822 124 22652 2,2UF 20% 50V
2519 2020 552 94427 NP0 50V 100P +/-5% R 2663 4822 124 22652 2,2UF 20% 50V
2520 2020 552 94427 NP0 50V 100P +/-5% R 2664 2020 552 94427 NP0 50V 100P +/-5% R
2521 4822 126 13956 68PF 5% NP0 63V 2665 5322 126 11578 1NF 10% X7R 50V /21M/30
2522 4822 126 13956 68PF 5% NP0 63V 2666 3198 017 44740 Y5V 10V 470N COL
2523 4822 124 40433 47UF 20% 25V 2667 2020 012 93547 ELCAP 63V S 100U +/-20%
2524 4822 126 14238 X7R 50V 2N2 COL R
2525 4822 124 40196 220UF 20% 16V
2526 4822 124 81151 22UF 50V
- RESISTORS -
2527 3198 017 44740 Y5V 10V 470N COL
2528 2238 586 59812 Y5V50V 100N +80/-20% 3101 4822 051 30333 33K00 5% 0,062W /21M/30/34
3102 4822 117 13632 100K 1% 0.62W /21M/30/34
2529 4822 126 13193 4,7NF10% X7R 63V 3103 4822 117 12902 8K2 1% 0.063W /21M/30/34
2530 4822 126 13193 4,7NF10% X7R 63V 3104 4822 117 13577 330R 1% 1,25W /21M/30/34
2537 4822 121 42408 220NF 5% 63V 3105 4822 051 30221 220R00 5% 0,062W
2538 4822 121 42408 220NF 5% 63V
2539 5322 121 42661 330NF 5% 63V 3130 4822 117 12968 820R 5% 0,62W /22
3131 4822 117 12968 820R 5% 0,62W /22
2540 5322 121 42661 330NF 5% 63V 3132 4822 051 30479 47R00 5% 0,062W
2541 4822 121 51252 470NF 5% 63V 3134 4822 051 30223 22K00 5% 0,062W
2542 4822 121 51252 470NF 5% 63V 3135 4822 051 30102 1K00 5% 0,062W /22
2543 2020 552 94427 NP0 50V 100P +/-5% R
2546 2238 586 59812 Y5V 50V 100N +80/-20% 3141 4822 051 30563 56K00 5% 0,062W
3142 4822 100 12159 100K 30%
2547 3198 017 44740 Y5V 10V 470N COL 3143 4822 051 30223 22K00 5% 0,062W /22/34
2549 4822 124 40196 220UF 20% 16V 3144 4822 051 30102 1K00 5% 0,062W /22/34
2560 4822 122 33741 10PF 10% NP0 50V 3145 4822 051 30222 2K20 5% 0,062W
2561 4822 122 33741 10PF 10% NP0 50V
2563 3198 016 31020 NP0 25V 1N 3146 4822 117 12139 22R 5% 0,062W
3150 4822 051 30103 10K00 5% 0,062W /22
2564 3198 016 31020 NP0 25V 1N 3151 4822 051 30683 68K00 5% 0,062W /22
2567 3198 017 44740 Y5V 10V 470N COL 3152 4822 051 30471 470R00 5% 0,062W
2568 3198 017 34730 X7R 16V 47N COL 3153 4822 051 30471
470R00 5% 0,062W
