Philips FW C330 - MECHANICAL PARTSLIST - MAIN UNIT

12-2
12-2
SCREW LISTS - MAIN UNIT
185 D3 x 12
186 D3 x 12
211 D3 x 12
212 D3 x 12
213 D3 x 12
214 D3 x 12
215 D3 x 12
226 M3 x 6
227 M3 x 6
231 M3 x 10
232 M3 x 10
233 M3 x 10
276 M3 x 6
277 M3 x 10
283 D3 x 12
287 D3 x 12
292 D3 x 12
293 D3 x 12
294 D3 x 10
297 D3 x 12
298 D3 x 12
300 D3 x 12
MECHANICAL PARTSLIST - MAIN UNIT ACCESSORIES
101 3140 117 64140 CABINET FRONT /21M 350 3140 118 51230 BOX SPK ASSY FWB-C330/01
101 3140 117 64120 CABINET FRONT /22/34 351 4822 303 50063 FM AERIAL
101 3140 117 66360 CABINET FRONT /30 356 3139 118 79300 REMOTE CONTROL
103 3140 117 64160 COVER CDC PANEL 384 2422 549 45067 ANT AM LOOP LAN-006 B
106 3140 117 64170 COVER TRAY CDC 387 3140 115 29760 IFU FW-C330 /21M/30
108 4822 454 13408 BADGE PHILIPS 387 3140 115 29740 IFU FW-C330 /22
128 3140 117 64210 WINDOW DISPLAY /21M 387 3140 115 29750 IFU FW-C330 /34
128 3140 117 64190 WINDOW DISPLAY /22/34
128 3140 117 66520 WINDOW DISPLAY /30
133 3140 117 65270 KNOB KARAOKE
134 3140 117 64230 BUTTON SET POWER
135 3140 117 65220 BUTTON SET SOURCE /21M/30
135 3140 117 65020 BUTTON SET SOURCE /22/34
136 3140 117 65030 BUTTON SET CONTROL
138 3140 117 64240 KNOB JOG ROT
139 3140 117 64250 KNOB VOL ROT
158 3140 117 64260 COVER CASS RIGHT
159 3140 117 64270 COVER CASS LEFT
160 3140 117 66370 LENS CASS RIGHT
162 3140 117 66380 LENS CASS LEFT
199 4822 402 10621 PUSH-CATCH
200 4822 529 10322 DAMPER ASSY
201 3139 114 68640 PUSH CATCH LEFT
203 4822 492 11344 SPRING COMPRESSION
204 4822 402 11246 BRACKET RIGHT
205 4822 402 11245 BRACKET LEFT
206 3139 111 01380 SPRING TORSION RIGHT
207 3139 111 01390 SPRING TORSION LEFT
209 4822 492 70231 SPRING
242 4822 462 40683 FOOT, RUBBER
253 3139 114 70930 PANEL LEFT
254 3139 114 70940 PANEL RIGHT
255 3139 114 70960 COVER TOP
268 3140 113 21880 MAINS CORD RELIEF
275 4822 492 11735 SPRING TRANS
385 2422 070 98244 MAINS CORD /21M/22/34
385 2422 070 98148 MAINS CORD /30
1400 3139 110 35940 FFC FOIL 30P/180/30P AD /21M/30
1400 3139 110 35930 FFC FOIL 32P/180/32P AD /22 34
1402 4822 320 12703 7P - 140MM
1500 3139 110 35920 FFC FOIL 04P/140/04P AD /21M
1700 4822 320 12654 7P - 220MM
1800 3139 110 35880 FFC FOIL 15P/180/15P BD
5001 3139 118 32610 POWER TRANSFORMER /21M
5001 3139 118 32740
POWER TRANSFORMER /22/30/34
Note :Only the parts mentioned in this list are normal
service spare parts.
!
!
!
!

