Philips FW-C399 - Location of PC Boards; Version Variations

1-2
LOCATION OF PC BOARDS
/21 /21M /22 /30 /33 /34 /37
Karaoke x x x
News x x
RDS x x
Rotary Encoder (volume control) x x xxxxx
Jog Shuttle x x xxxxx
Voltage Selector x x
Aux Input x x xxxxx
Digital Output
Headphone Socket x x xxxxx
Line Output
Matrix Surround Loudspeakers
Standby - FTD Clock Display x x xxxxx
ECO Standby - Dark x x xxxxx
ECO6 Tuner board - System Non-Cenelec x x x x x x
ECO6 Tuner board - System Cenelec x
ETF7 Tape Module: Non-Autoreverse Ferro x x xxxxx
MMPWR 100W Module:
100W Phase Inverse version x x xxxxx
VERSION VARIATIONS:
Type /Versions: FW-C399
Features &
Board in used:
ETF7
BOARD
MAINS
BOARD
LEFT/RIGHT AMPLIFIER
& SUPPLY BOARD
MAINS SOCKET
BOARD
TUNER
BOARD
CD KEY BOARD
FRONT
BOARD
KARAOKE
BOARD
AF9
BOARD
HEADPHONE
BOARD
CD
BOARD
