13-2 13-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
185 D3 x 12
186 D3 x 12
211 D3 x 12
212 D3 x 12
213 D3 x 12
214 D3 x 12
215 D3 x 12
226 M3 x 6
227 M3 x 10
229 M3 x 10
230 D3 x 10
231 M3 x 10
232 M3 x 6
276 M3 x 6
277 M3 x 10
278 D3 x 16
279 D3 x 12
280 D3 x 12
283 D3 x 12
287 D3 x 12
292 D3 x 12
293 D3 x 12
294 M3 x 10
295 D3 x 12
296 D3 x 12
297 D3 x 12
299 D3 x 12
300 D3 x 12
301 D3 x 12
302 D3 x 12
304 D3 x 12
101 3139 118 16480 Cabinet Front /21/21M
101 3139 118 16580 Cabinet Front /22
101 3139 118 16100 Cabinet Front /37
103 3139 118 16110 Cover Front CDC
105 3139 118 16500 Button Set CDC LPS
106 3139 118 16130 Cover Tray CDC
107 3139 118 16140 Button Set Open/Close
108 4822 454 13408 Badge Philips
128 3139 118 16490 Window Display /21/21M
128 3139 118 16590 Window Display /22
128 3139 118 16150 Window Display /37
129 3139 118 16160 Cover Front Display
130 3139 118 16170 Cover Front Ornamental
131 3139 114 71350 Light guide Source Select
132 3139 118 16180 Button Set Source
134 3139 118 16190 Button Set Control & VCD
135 3139 118 16200 Button Max
136 3139 118 16210 Button DSC/DBB/VEC/IS
137 3139 118 16220 Ring Volume
138 3139 118 16230 Knob Rotary
139 3139 118 13190 Knob Volume
140 3139 114 71330 Light guide DSC/DBB/VEC/IS
142 3139 114 74610 Knob Karaoke /21/21M
142 3139 118 16600 Button Set RDS/News /22
158 3139 118 16250 Cover Cassette Right
159 3139 118 16260 Cover Cassette Left
160 3139 118 13900 Lens Cassette Right
161 3139 118 13890 Lens Cassette Left
197 3139 114 68630 Door Cassette Right ETF
198 3139 114 68620 Door Cassette Left ETF
199 4822 402 10621 Push-Catch
200 4822 529 10322 Damper Assembly
201 3139 114 68640 Push Catch Left
203 4822 492 11344 Spring Compression
204 4822 402 11246 Bracket Right
205 4822 402 11245 Bracket Left
206 3139 111 01380 Spring Torsion Right
207 3139 111 01390 Spring Torsion Left
209 4822 492 42787 Spring Cassette
242 4822 462 40683 Foot Rubber (SQ)
251 3139 114 70970 Bracket CDC Left
252 3139 114 70980 Bracket CDC Right
253 3139 114 73570 Panel Left Grey /21/21M/22
253 3139 114 74780 Panel Left Grey V2 /37
254 3139 114 73580 Panel Right Grey /21/21M/22
254 3139 114 74790 Panel Right Grey V2 /37
255 3139 114 73590 Cover Top Grey /21/21M/22
255 3139 114 74800 Cover Top Grey V2 /37
256 3139 114 73140 Panel Rear /21
256 3139 114 73880 Panel Rear /21M/22
256 3139 114 74850 Panel Rear V2 /37
271 3139 114 71010 Stopper Heat sink
350 3139 118 79070 Loudspeaker Box /21/21M/22
350 3139 118 79080 Loudspeaker Box /37
351 4822 303 50063 FM Antenna /21/21M/22
351 4822 320 11094 FM Antenna /37
356 3139 228 89680 Remote Control RC282432/01
384 2422 549 45067 AM Loop Antenna
385 2422 070 98151
!
Mains Cord /21/21M/22
385 2422 070 98152
!
Mains Cord /37
386 4822 263 21092
!
Adapter Plug /21
387 3139 115 21120 Instruction For Use /21/21M
387 3139 115 21220 Instruction For Use /22
387 3139 115 21070 Instruction For Use /37
1120 4822 361 11161 Fan KD1206PTS3
1200 3139 110 35010 Flex Cable 7 Pin 34cm AD
1300 3139 110 35350 Flex Cable 11 Pin 22cm AD
1400 3139 110 35110 Flex Cable 4 Pin 22cm AD
1401 4822 320 12703 Flex Cable 7 Pin 14cm BD
1402 3139 110 35100 Flex Cable 19 Pin 14cm AD
1403 3139 110 34610 Flex Cable 11 Pin 18cm AD
1500 3139 110 33960 Flex Cable 4 Pin 12cm BD
1501 3139 110 33960 Flex Cable 4 Pin 12cm BD /21/
21M
1600 3139 110 35050 Flex Cable 8 Pin 22cm AD
1700 4822 320 12752 Flex Cable 7 Pin 18cm AD
1800 3139 110 35880 Flex Cable 15 Pin 18cm BD
5001 3103 308 30700
!
Mains Transformer /21/21M
5001 3103 308 30690
!
Mains Transformer /22
5001 3103 308 30680
!
Mains Transformer /37
Note: Only the parts mentioned in this list are normal
service spare parts.
