Philips FWM35/21 - Mechanical Exploded View

11-1
11-1
1
3
4
5
6
7
8
9
11
12-(2X)
12
13
14
15
17
16
18
19
21
22
23
24
25
26
27
28
33
34
35
32
29
31
36
37
38
38-(2X)
51-(2X)
52-(49X)
53-(2X)
54-(2X)
55-(4X)
56-(2X)
57-(9X)
58-(4X)
59-(4X)
41
42
43
2
NO. DESCRIPTION. QTY.
52 HARDEN SCREW 3X10 49
53 SELF TAPPING SCREW 3X12 2
54 SELF TAPPING SCREW 3X14 2
55 HARDEN SCREW/WH 3X12 4
56 HARDEN SCREW STT3X6 2
57 HARDEN SCREW TT3X8 9
58 HARDEN SCREW TT/WH3X6 4
59 HARDEN SCREW TT/WH 3X10 4
SCREW LIST
MECHANICAL EXPLODED VIEW
