Philips GC7320 Service Manual

GC7320
5-7
TRAY RUBBER CAP 30
TRAY ASSY 33
DOOR ASSY 35
Remove TRAY RUBBER CAP 30 (3x)
Remove Screw F1, F2, F3
Disassemble TRAY ASSY 33
Remove Screw G
Disassemble DOOR ASSY 35
FRONT PANEL PRINTED 37
POWER BOARD 43
LIGHT SWITCH 44
Remove TRAY RUBBER CAP 30 (3x)
Remove Screw F1, F2, F3
Disassemble TRAY ASSY 33
Remove Screw H1, H2
Disassemble FRONT PANEL 37
Disassemble LIGHT SWITCH 44
Disassemble POWER BOARD 43
DISASSEMBLY ADVICE - STAND
WATER TANK ASSY 34
HOSE CORD CAP 36
BOILER ASSY 38
BRAIDED RUBBER HOSE -
BOILER 41
PUMP ASSY 45
INLET TUBE - PUMP 46
DE-AIR TUBE 47
RINSE RUBBER COUPLING 50
RINSE BUSH 51
RINSE CAP ASSY 52
Remove TRAY RUBBER CAP 30 (3x)
Remove Screw F1, F2, F3
Disassemble TRAY ASSY 33
Remove Screw H1, H2
Disassemble FRONT PANEL 37
Disassemble HOSE CORD CAP 36
Disassemble RINSE CAP ASSY 52
Disassemble RINSE BUSH 51
Disassemble RINSE RUBBER COUPLING 50
Remove Screws K1, K2, K3, K4
Disconnect INLET TUBE - PUMP 46
Disconnect DE-AIR TUBE 47
Disassemble WATER TANK ASSY 34
Disassemble BRAIDED RUBBER HOSE - BOILER 41
Disassemble PUMP ASSY 45
Remove Torx screws L1, L2, L3
Disassemble TOP SPACER 48
Disassemble BOILER ASSY 38
PARTS LIST - STAND
Note: For Pos 45, please replace both components together when either one is faulty.
The 2 components come as a service kit.
Pos Service code Description
30
33
34
35
36
37
38
39
40
41
42
44
45
4239 015 57990
4239 021 47640
4239 021 47600
4239 021 47680
4239 026 30800
4239 021 47620
4239 021 39540
4239 017 10420
4239 017 09890
4239 015 56880
4239 010 10260
4239 017 11110
4239 022 61560
Tray rubber cap
Tray assy
Water tank assy
Door assy
Hose cord cap
Front panel printed
Boiler assy High End
Thermistor
Electrovalve
Braided rubber hose - boiler
Inox clamp - boiler
Light switch
Control board-Pump assy
High End
Pos Service code Description
46
47
48
49
50
51
52
55
56
57
58
65
4239 015 56860
4239 015 56870
4239 026 26120
4239 026 26110
4239 015 56760
4239 026 30820
4239 021 47630
4239 000 10100
4239 021 47610
4239 015 52340
4239 026 05990
4239 026 26480
Inlet tube - pump
De-air tube
Top spacer
Bottom spacer
Rinse rubber coupling
Rinse bush
Rinse cap assy
Cordset EU
Stand bottom assy
Bung
Filling cup
De-air valve High End

Philips GC7320 Specifications

Power

voltage	230 V
frequency	50-60 Hz
boiler wattage	1400 W
iron wattage	800 W

Steam Performance

maximum steam pressure	4.5 bars
continuous steam output	110 g/min

Weight and Dimensions

weight (including packaging)	6.1 kg
dimensions	429x400x206 mm
