Philips GC9940 - Ironing Board Disassembly; Ironing Board Parts List

GC9940
12-16
DISASSEMBLY ADVICE - IRONING BOARD
WIRE ASSY SIGNAL 71
FAN GASKET 68
FAN ASSY 69
Remove bolts R1 - R4
Disassemble Fan grille
Disconnect WIRE ASSY SIGNAL 71
Disassemble FAN GASKET 68
Disassemble FAN ASSY 69
BOARD HOUSING ACTIVE 64
Remove BOARD STICKER 67 (on Active Board)
Remove screws S1 - S20
Remove baord plugs T1 - T3
Disassemble BOARD HOUSING ACTIVE 64
Reassembly tip:
Adjust board plug C1, C2, C3 clockwise & counter-clockwise to
align screw holes between board frame & board housing before
screwing.
Reassembly tip:
Replace with new BOARD STICKER 67 after reassembling
BOARD HOUSING ACTIVE 64.
PARTS LIST - IRONING BOARD
Pos Service code Description
63
64
65
66
67
68
69
70
71
4239 017 12171
4239 021 49753
4239 026 33183
4239 021 49762
4239 026 25900
4239 015 56230
4239 017 11040
4239 017 10108
4239 017 76051
Wire assy Board chassis CW
Board housing Active
Cover button Refresh
Board housing Passive
Board sticker
Fan gasket
Fan
Board cover
Wire assy Signal - Shrink wrap
