PHILIPS MEDICAL SYSTEMS
2GETTING STARTED
PACKAGE CONTENTS
The HeartStart FR2+ Defibrillator is supplied with a standard long-life battery,
two sets of adult defibrillator pads with integrated cable and connector, and a
data card tray. Other accessories, including FR2 infant/child reduced-energy
defibrillator pads, an FR2+ rechargeable battery, and (for M3860A only, with
ECG display enabled) a three-wire FR2+ ECG assessment module, are available.
See Appendix A for a list of accessories and other recommended supplies.
SETUP OVERVIEW
Setting up the HeartStart FR2+ for use is quick and simple.
• Install a data card. (optional)
• Install a battery.
• Set the clock in the FR2+. (optional)
• Run the battery insertion selftest.
• Place the FR2+ with recommended accessories in a convenient
location.
INSTALLING THE DATA CARD
The HeartStart FR2+ comes with a data card tray, which should be kept in the
data card port even if no data card is used. If a data card is to be used, install it as
follows:
1. Load the data card face up into the data card tray, with the tray’s “tongue”
fitting over the matching yellow area on the data card.
2. Press the On/Off button to turn off the HeartStart FR2+ if it is on.
3. Hold the loaded data card tray by its handle and gently insert the tray all the
way into the defibrillator’s data card port until only the tab remains outside
the case.
The data card will automatically record incident data the next time the
HeartStart FR2+ is turned on.
